Image Sensor
|
1/1.9" progressive scan CMOS |
Max. Image Resolution
|
4096 x 2160 |
Signal System
|
PAL/NTSC |
White Balance
|
Auto / Manual /ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp |
Min.Illumination
|
F1.5, 50IRE, AGC On: Color: 0.002 lux, B/W : 0.0002 lux, 0 lux with IR |
AGC
|
Auto / Manual |
Digital Zoom
|
16x |
Focus mode
|
Auto / Semiautomatic / Manual |
BLC
|
ON/OFF |
HLC (High Light Compensation)
|
Support |
Ultra Defog
|
Support |
WDR
|
120dB |
Shutter Time
|
50Hz: 1~1/30,000s; 60Hz: 1~1/30,000s |
Privasi masking
|
24 privacy masks programmable; optional multiple colors and mosaics |
Focal Lenght (Zoom Ratio)
|
6.2 mm to 202 mm, 36x |
Min. working distance
|
10 ~1500mm(Wide-Tele) |
Focal length
|
5.7-205.2, 36x |
Angle of View
|
58.7-2.0 degree (Wide-Tele) |
Aperture range
|
ƒ/1.5 to ƒ/3.4 |
Zoom Speed
|
Approximately 3.3 s (optical wide to tele) |
Digital Noise Reduction
|
3D DNR |
Proportional zoom
|
Rotation speed can be adjusted automatically according to zoom multiples |
Preset freezing
|
Support |
Pan / Tilt / Rotate Range
|
360°endless/-20°~90°(Auto Flip) |
Pan / Tiltr speed
|
Pan Manual Speed: 0.1°~160°/s, Pan Preset Speed: 240°/s / Tilt Manual Speed: 0.1°~120°/s, Tilt Preset Speed: 200°/s |
Number of preset
|
300 |
Patrol
|
8 patrols, up to 32 presets per patrol |
Pattern
|
4 patterns, with the recording time not less than 10 minutes per pattern |
Power loss recovery
|
Support |
Park action
|
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan |
PTZ position display
|
ON/OFF |
Smart-tracking:
|
Manual/ Panorama/ Intrusion trigger/ Line crossing trigger/ Region entrance trigger/ Region exiting trigger Smart tracking when patrol between multiple scenarios |
Wiper:
|
Optional |
IR irradiation distance
|
200m |
IR irradiation angle
|
Adjustable by zoom |
Alarm Inputs / Output
|
7 Inputs / 2 Output: |
Alarm Actions
|
Preset, patrol, pattern, SD/SDHC card recording, relay output, notifi cation on client |
Shutter speed
|
1 ~1/10,000s |
Monitor Output
|
1.0Vp-p / 75Ω, NTSC (or PAL) composite, BNC |
Audio Input
|
1 Mic in/Line in interface Line input: 2-2.4V[p-p]; output impedance: 1KΩ, ±10% |
Audio Output
|
1 Audio output interface Line level, impedance: 600Ω |
Day/Night
|
IR Cut Filter |
Max. Resolution
|
1920×1080 |
Ethernet
|
10Base -T, /100Base-TX, RJ45 Connector |
Image compression
|
H.264/MJPEG/MPEG4, H.264 encoding with Baseline/Main/High profile |
ROI
|
Support 24 areas with adjustable levels |
Audio Compression
|
G.711ulaw/G.711alaw/G.726/MP2L2/G.722 |
Protocol
|
IPv4/IPv6, HTTP, HTTPS, 802.1X, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE |
Simultaneous live view
|
Up to 20 users |
Main Stream
|
50Hz: 25fps(1920×1080), 25fps(1280×960), 25fps (1280×720) 60Hz: 30fps(1920×1080), 30fps(1280×960), 30fps (1280×720) |
Sub Stream
|
50Hz: 25fps(704×576), 25fps (352×288), 25fps (176×144) 60Hz: 30fps(704×480), 30fps (352×240), 30fps (176×120) |
Third Stream
|
50Hz: 25fps(1920×1080, 1280×960, 1280×720, 704×576, 352×288, 176×144) 60Hz: 30fps(1920×1080, 1280×960, 1280×720, 704×480, 352×240, 176×120) |
Mini SD Memory Card
|
Support up to 128GB Micro SD/SDHC/SDXC card. Support Edge recording |
User/Host Leve
|
Up to 32 users,3 Levels: Administrator, Operator and User |
Security measures
|
User authentication (ID and PW), Host authentication (MAC address) IP address filtering |
Camera Control
|
Pan/Tilt, Zoom, Focus, Click centering, Zoom by mouse dragging, Iris, preset calling and programming, auto mode |
Date Display Format
|
Time: Week: Date, 6 formats on the Client |
Client
|
Support iVMS-4200 |
Web Browser
|
IE 7+, Chrome 18 +, Firefox 5.0 +, Safari 5.02 + |
RS-485 Interface
|
HIKVISION, Pelco-P, Pelco-D, self-adaptive |
Menu Language
|
English |
Power Supply
|
24 VAC & Hi-PoE |
Power Consumption (±10%)
|
Max.60W |
Working Temperature/Humidity
|
-40°C ~ 65°C (-40°F ~ 149°F) |
Protection level
|
IP66, IK10, TVS 6,000V lightning protection, surge protection and voltage transient protection |
Mounting
|
Various mounting modes optional |
Mount option
|
Long-arm wall mount: DS-1602ZJ; Corner mount: DS-1602ZJ-corner; Pole Mount: DS-1602ZJ-pole; Power box mount:DS-1602ZJ-box; Swan-neck mount: DS-1619ZJ.) |
Dimensions (mm)
|
Φ178.3 mm × 331.0 mm (Φ7.02" × 13.03") |
Weight (approx.)
|
~8 kg (~17.64 lbs) |
Certifications
|
FCC, CE, UL, RoHS, IEC/EN 61000, IEC/EN 55022, IEC/EN 55024, IEC/EN60950-1) |
Humidity
|
90% or less |
