AXIS XF60-Q2901 UL

Telp untuk Harga

XF60-Q2901 UL 8.3FPS 19MM -50C 110V IA
- 110 VAC power
- Suitable for onshore, offshore, marine, and heavy industrial environments
- Integrates with other equipment, such as access control and fire alarms
- Image settings include sharpness, automatic gain control, exposure zones, max gain, rotation, palette, isothermal palette, compression, mirroring, text and image overlay, and privacy masks
- Tells the temperature of a particular area
- Temperature alarm and isothermal palettes
- Spot temperature reading
- Wide temperature range
- Includes video motion and shock detection
- Support for microSD cards, and recording to network-attached storage (NAS)
- IP67-rated stainless steel housing that is suitable for outdoor use

Qty:

Overview
Specifications
Contact Us

The XF60-Q2901 Explosion-Protected Temperature Alarm Thermal Network Bullet Camera from Axis Communications is equipped with an uncooled microbolometer image sensor to capture 336 x 256 resolution video at up to 8.3 fps that is scalable up to 720 x 576 resolution. The 19mm fixed lens has a 17° horizontal field of view. This camera supports temperature alarm zones that are triggered based on temperature deviations. It can visualize hot spots thanks to isothermal palettes that identify overheated equipment or areas. A 64GB Axis Surveillance microSDXC card is included for edge storage.

H.264 and MJPEG compression reduces bandwidth usage and storage requirements. In addition, video can be transmitted in three H.264 and MJPEG individual streams, and bandwidth and frame rates are controllable for further customization of your network. Once configured, your surveillance network is secured with safety features that include password protection, IP address filtering, HTTPS encryption, digest authentication, user access logging, and centralized certificate management.

This device is ONVIF-compliant for Profiles S and G, making it compatible with a wide range of surveillance devices. The camera's stainless steel (SAE 316L) housing is certified for hazardous areas and prevents sparks and explosions from escaping and igniting gases, vapors, fibers, or dust in the surrounding air. The stainless steel housing is IP67-rated, making it suitable for outdoor use

Spesifikasi produk

Lens	Athermalized 19mm, f/1.25 Horizontal Field of View: 17° Minimum Focus Distance: 354.3" / 9.5 m
Day/Night	Automatically removable infrared-cut filter
Minimum Ilumination	Color: 0.5 lux at 30 IRE F1.6 B/W: 0.04 lux at 30 IRE F1.6
Shutter Time	1/28000 s to 2 s
Pant/Tilt/Zoom	18x optical zoom and 12x digital zoom, total 2 16x zoom 64 preset positions
Video	H.264 (MPEG - 4 P art 1 0/A VC) Baseline, and Main profiles Motion JPEG
Resolution	1920x1 080 HD TV 1 080p to 160x90
Frame Rate	Up to 30/25 fps (60/50 Hz) in all resolutions
Video Streaming	Multiple, individually configurable streams in H.264 and Motion JPEG Controllable frame rate and bandwidth VBR/CBR H.264
Image settings	Compression, color , brightness, sharpness, white balance, exposure control, exposure zones, backlight compensation, WDR – dynamic contrast, fine tuning of behavior at low light, rotation, text and image overlay , day/night shift level
Security	P assword protection, IP address filtering, HTTPS a encryption, Digest authentication, User access log, Centralized Certificate Management
Supported Protocols	IPv4/v6, HTTP , HTTPS a , SSL/TLS a , QoS Layer 3 DiffServ , FTP , SFTP , CIFS/SMB, SMTP , Bonjour , UPnP T M , SNMP v1/v2c/v3 (MIB - II), DNS, DynDNS, NTP , RTSP , RTP , T CP , UDP , IGMP , RT CP , ICMP , DHCP , ARP , SOCKS, SSH
Aplication Programming Interface	Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www .axis.com AXIS Video Hosting System (A VHS) with One - Click Connection ONVIF® Profile S and ONVIF® Profile G, specification at www .onvif.org
Analytics	AXIS Video Motion Detection 4, active tampering alarm Support for AXIS Camera Application Platform enabling installation of third - party applications, see www .axis.com/acap
Event Triggers	Analytics, Edge storage events
Event actions	File upload: FTP, HTTP, network share and email Notification: email, HTTP and TCP Pre- and post-alarm video buffering
Data streaming	Event data
Built-in installation aids	Pixel counter
Casing	IP66 - and IP67 - rated, electropolished SAE 3 16L stainless steel casing for maximum corrosion protection
Memory	256 MB RAM, 128 MB Flash
Power	24 Volt
Connectors	XF40 - Q1765 models: Three M20 conduit entries XF40 - Q1765 UL models: Three 3/4" NPT conduit entires
Storage	Support for microSD/microSDHC/microSDXC card Support for SD card encryption Support for recording to network - attached storage (NAS) For SD card and NAS recommendations see www .axis.com
Operation condition	XF40 - Q1765: - 40 °C to 7 0 °C ( - 40 °F to 158 °F) XF40 - Q1765 - 60 C: - 60 °C to 40 °C ( - 76 °F to 1 04 °F) XF40 - Q1765 - 50 C UL: - 50 °C to 7 0 °C ( - 58 °F to 158 °F) Humidity 1 0–1 00% RH (condensing)
Image Sensor	Uncooled microbolometer 336 x 256 Pixel Size: 17 µm Spectral Range: 8-14 µm
Detection range	The size of a monitored object is recommended to cover at least 10 x 10 pixels in 336 x 256
Sensitivity	NETD <50mK
Thermography	Object Temperature Range: -40 to 1022°F / -40 to 550°C
