Brand: Axis

Axis Q1910-E

Telp untuk Harga

Thermal imaging for IP-Surveillance
Outdoor-ready with window heater
Standard Power over Ethernet (IEEE 802.3af)
Multiple H.264 streams with individual palettes
Intelligent video capabilities

Qty:

Overview
Specifications
Contact Us

AXIS Q1910-E THERMAL NETWORK CAMERA

Kamera network AXIS Q1910-E merupakan kamera yang dapat memantau dengan mendeteksi suhu panas pada area yang terpantau oleh CCTV AXIS Q1910-E, sehingga kamera ini mampu mengawasi lebih baik dari CCTV biasa lainnya dan mampu melihat apa yang tidak terlihat oleh kamera biasa. Q1910-E dapat digunakan untuk pengawasan di luar ruangan seperti lokasi parker kendaraan atau area umum lainnya. Kamera ini memiliki tingkat sensitifitas NETD < 100 mK.

AXIS Q1910-E sangat cocok untuk digunakan untuk mengawasi koridor atau ruangan yang gelap dan minim bercahaya. Kamera AXIS Q1910-E ialah kamera yang sangat cerdas sehingga sangat membantu untuk mengawasi berbagai kejadian dan mengurangi tindak kriminal yang marak terjadi. Kamera model ini juga dapat digunakan untuk mengawasi kendaran yang terparkir pada pasar swalayan atau area yang memerlukan pengawasan secara khusus dan ketat.

FITUR AXIS Q1910-E

Video resolusi 160x128 namun dapat ditingkatkan hingga 720x576 (D1).
Video streaming H.264, Motion JPEG, VBR/CBR H.264.
Mampu bertahan pada suhu -40 °C to 50 °C (-40 °F to 122 °F), dengan casing dengan ketahanan IP66.
Konektor RJ45 10BASE-T/100BASE-TX.
Memori: 128 MB RAM, 128 MB Flash.
Power over Ethernet IEEE 802.3af Class 3 max 13 W, max 18 VA Power supply tidak termasuk.
Berat CCTV 3520 g (7.76 lb.).
Thermal camera, SD/SDHC memory card slot.
Built-in heater for the window.
Kamera yang dapat memantau dengan sangat baik.

Kami menyediakan Network Camera AXIS Q1910-E murah dan paket DVR murah mulai dari jual IP camera, jual IR camera, jual Analog camera, jual Dome camera, jual Cube camera, jual Box camera serta jual DVR 4 channels, jual DVR 6 channels, jual DVR 8 channels, jual DVR 12 channels, jual DVR 16 channels, jual DVR 32 channels. Kamera network AXIS Q1910-E hanya bisa Anda dapatkan hanya di JakartaCCTV dengan harga network cctv murah. Jual 16CH DVRmurah di Jakarta hanya di JakartaCCTV. JakartaCCTV terpercaya dan berpengalaman. Pemasangan CCTV yang langsung ditangani oleh teknisi yang berpengalaman.

Spesifikasi produk

Image Sensor	Uncooled Micro bolometer 160x120, pixel size: 25 μm, spectral range: 8-14µm
Lens	f 13 mm, F1.25. Angle of view, horizontal: 17°
Detection range	Detection (1.5 pixels on target) : (Human 1.8 x 0.5 m: 260 m / 284 yd. Vehicle Vehicle: 1.4 x 4.0 m: 800 m / 875 yd.), Recognition (6 pixels on target) : (Human 1.8 x 0.5 m: 65 m / 71 yd. Vehicle Vehicle: 1.4 x 4.0 m: 200 m / 219 yd.), Identification (12 pixels on target) : (Human 1.8 x 0.5 m: 30 m / 33 yd. Vehicle Vehicle: 1.4 x 4.0 m: 100 m / 109 yd.)
Sensitivity	NETD < 100 mK
Video Compression	H.264 (MPEG-4 Part 10/AVC) Motion JPEG
Video Resolution	Sensor is 160x128. Image can be scaled up to 720x576 (D1) and to standard VGA resolutions
Video Framerate	8.33 fps
Video Streaming	At least 5 streams in H.264 and Motion JPEG: simultaneous, individually configured streams in max. resolution at 8.33 fps Controllable frame rate and bandwidth. VBR/CBR H.264
Image settings	Compression, brightness, exposure control, rotation, mirroring of images, text and image overlay, privacy mask, multiple palettes
Audio streaming	Two-way, half duplex
Audio Compression	AAC LC 8/16 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz Configurable bit rate
Audio Input / Output	External microphone or line input, line output
Security	Password protection, IP address filtering, HTTPS* encryption, IEEE 802.1X* network access control, digest authentication, user access log
Protocol Support	IPv4/v6, HTTP, HTTPS*, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS. Wide range of PT heads supported (drivers available for download at www.axis.com).
Application Programming Interface	Open API for software integration, including the ONVIF specification available at www.onvif.org, as well as VAPIX® and AXIS Camera Application Platform from Axis Communications, specifications available at www.axis.com Support for AXIS Video Hosting System (AVHS) with One-Click Camera connection
Intelligent Video	Video motion detection, active tampering alarm, audio detection. Support for AXIS Camera Application Platform enables installation of additional applications
Alarm Triggers	Intelligent video and external input
Alarm Events	File upload via FTP, HTTP and email; notification via email, HTTP and TCP; external output activation
Casing	IP66-rated aluminum casing and a germanium window
Processor and Memory	128 MB RAM, 128 MB Flash
Power	Power over Ethernet IEEE 802.3af Class 3 8-20 V DC / 20-24 V AC 50-60 Hz max 13 W, max 18 VA Power supply not included
Connectors	RJ-45 10BASE-T/100BASE-TX PoE, terminal block for power, terminal block for two configurable inputs/outputs 3.5 mm mic/line in, 3.5 mm line out RS-422/RS-485 Terminal block for AXIS Q1910/-E heater
Local Storage	SD/SDHC memory card slot (card is not included)
Operating Conditions	Shock resistance: 70 g shock pulse with a 11 ms half-sine profile Vibration resistance: 4.3 g random vibration for 8 hours (three axes) -40 °C to 50 °C (-40 °F to 122 °F ), IP66
Approvals	EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 50121-4, EN 61000-6-1, EN 61000-6-2, EN 60950-1, FCC Part 15, Subpart B, Class B, VCCI, Class B ITE, C-tick AS/NZS CISPR 22, ICES-003, Class B, IP66
Weight	3520 g (7.76 lb.)
Included accessories	wall mount bracket, 5 m (16 ft.) Ethernet cable
Optional accessories	Wall bracket accessories Pan/tilt motor AXIS Camera Station and video management software from Axis’ Application Development Partners. For more information, see www.axis.com/products/video/software/
