Image Sensor
|
Progressive scan CMOS 1/3” |
Lens
|
f=5.1–51 mm, F1.8–2.1, Autofocus, Automatic day/night Horizontal angle of view: 48.1°–5.1° M37x0.75 mounting thread for optional lens adaptor |
Min.Illumination
|
Color: 2 lux at 30 IRE, F1.8 B/W: 0.2 lux at 30 IRE, F1.8 |
Shutter Time
|
1/10000 s to 1/2 s |
Pan/ Tilt/ Zoom
|
Zoom: 10x optical and 12x digital, total 120x |
Video Compression
|
H.264 (MPEG-4 Part 10/AVC) Motion JPEG |
Video Resolution
|
HDTV 1080i 1920x1080, HDTV 720p 1280x720 Standard NTSC/PAL for installation |
Video Frame Rate
|
H.264: 25/30 fps in all resolutions Motion JPEG: 25/30 fps in all resolutions |
Video Streaming
|
Multiple, individually configurable streams in H.264 and Motion JPEG Controllable frame rate and bandwidth, VBR/CBR H.264 |
Image settings
|
Compression, Brightness, Sharpness, White balance, Exposure control, Backlight compensation, Rotation - including Corridor Format, Text and image overlay, Privacy mask, Mirroring of images |
Audio streaming
|
Two-way |
Audio Compression
|
AAC LC 8/16 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz Configurable bit rate |
Audio Input / Output
|
Built-in microphone, external microphone or line input, line output |
Security
|
Password protection, IP address filtering, HTTPSa encryption, IEEE 802.1Xa network access control, Digest authentication, User access log |
Protocol Support
|
IPv4/v6, HTTP, HTTPSa , QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH. Wide range of PT heads supported (drivers available for download at www.axis.com) |
Application Programming Interface
|
Open API for software integration, including VAPIX® and AXIS Camera Application Platform, specifications at www.axis.com AXIS Video Hosting System (AVHS) with One-Click Camera Connection. ONVIF Profile S, specification at www.onvif.org |
Intelligent Video
|
Video motion detection, Active tampering alarm, Audio detection, Gatekeeper, AXIS Camera Application Platform enabling installation of additional applications |
Trigger Events
|
Video motion detection, Active tampering alarm, Audio detection, Temperature, External input, AXIS Camera Application Platform |
Event actions
|
File upload: FTP, HTTP and email Notification: email, HTTP and TCP Pre- and post-alarm video buffering External output activation |
Casing
|
Camera: Metal (zinc) |
Memory
|
256 MB RAM, 128 MB Flash |
Power
|
8–20 V DC max. 11.2 W; 20–24 V AC max. 17.4 VA; Power over Ethernet IEEE 802.3af Class 3 |
Connectors
|
RJ45 10BASE-T/100BASE-TX PoE, Terminal block for power I/O terminal block for two configurable inputs/outputs 3.5 mm mic/line in, 3.5 mm line out, RS422/RS485 Video out: 3x RCA Y/Pb/Pr (HD), 1x RCA Composite (SD) |
Edge Storage
|
SD/SDHC memory card slot (card not included) |
Operating Conditions
|
0 °C to 45 °C (32 °F to 113 °F); Humidity 10–85% RH (non-condensing) |
Approvals
|
EN 61000-3-2, EN 61000-3-3 |
Weight
|
1 kg (2.2 lb) |
Included accessories
|
Installation Guide, Installation and Management Software CD, Windows decoder 1-user license, Mounting and connector kits |
Video Management Software
|
AXIS Camera Station and video management software from Axis’ Application Development Partners (not included). For more information, see www.axis.com/products/video/software |
