AXIS Q1614 NETWORK CAMERA

Network Camera AXIS Q1614 harga ekonomis dan bersahabat di Jakarta. Network kamera adalah kamera pengawas yang dapat terhubung dengan jaringan, sehingga pengguna dapat memantau aktifitas dari jarak jauh. AXIS CCTV telah di dukung oleh teknologi terbaru yang sangat modern dan canggih sehingga sangat tepat untuk pengawasan di era saat ini. Adapun beragam keunggulan yang ditawarkan oleh Q1614 yaitu mampu bertahan pada suhu 0 °C to 50 °C (32 °F to 122 °F) dengan ketahan IP66 sehingga mampu bertahan terhadap lingkungan keras sekitar kamera terpasang. Kamera AXIS Q1614 dengan Day/Night system yang mampu beroperasi dengan sangat baik pada siang maupun malam hari.

Kamera dengan kemampuan pemantauan yang luar biasa mendukung beberapa protocol seperti IPv4/v6, HTTP, HTTPSc , SSL/TLSc , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS. Fitur edge storage merupakan fitur yang menyediakan slot untuk penyimpanan kartu microSD langsung pada kamera. Kamera ini beroperasi dengan memori 256 MB RAM, 128 MB Flash.

FITUR AXIS Q1614

Video kamera CCTV dengan kualitas luar biasa.
Multiple-stream H 264.
Terminal block for 1 alarm input and 1 output RS485/RS422, Terminal block for two configurable inputs/outputs (12 V DC output, max. load 50 mA).
Memori: 256 MB RAM, 128 MB Flash.
Berat CCTV 925 g (2 lb).
Edge Storage, untuk kartu microSD sebagai sarana penyimpanan hasil rekaman.
Kamera yang mudah dipasang dengan berbagai posisi.

Kami menyediakan paket CCTV murah dan paket DVR murah mulai dari jual IP camera, jual IR camera, jual Analog camera, jual Dome camera, jual Cube camera, jual Box camera serta jual DVR 4 channels, jual DVR 6 channels, jual DVR 8 channels, jual DVR 12 channels, jual DVR 16 channels, jual DVR 32 channels. Kamera network AXIS Q1614 hanya bisa Anda dapatkan hanya di JakartaCCTV dengan harga network cctv murah. Jual 16CH DVRmurah di Jakarta hanya di JakartaCCTV. JakartaCCTV terpercaya dan berpengalaman. Pemasangan CCTV yang langsung ditangani oleh teknisi yang berpengalaman.

Spesifikasi produk

Image Sensor	Progressive scan RGB CMOS 1/3”
Lens	Progressive scan RGB CMOS 1/3” 2.8–8 mm: 100°–34° viewa , F1.2
Day/Night	Automatically removable infrared-cut filter
Min.Illumination	Extended D1: Color: 0.05 lux, B/W: 0.008 lux, F1.2; HDTV 720p 25/30 fps: Color: 0.1 lux, B/W: 0.02 lux, F1.2; With WDR-Dynamic Capture: Color: 0.4 lux, B/W: 0.06 lux, F1.2;
Shutter Time	1/43500 to 2 s
Pan/ Tilt/ Zoom	Digital PTZ, Uploadable PTZ driver (Pelco D pre-installed)
Video Compression	H.264 (MPEG-4 Part 10/AVC), H.264 Main and Baseline Profile, Motion JPEG
Video Resolution	HDTV 720p 25/30 fps: 1280x960b to 160x90 Extended D1: 768x576 to 160x90
Video Framerate	50/60 fps (no WDR)
Video Streaming	Multiple, individually configurable streams in H.264/Motion JPEG, Controllable frame rate and bandwidth, VBR H.264
Image settings	Auto-rotation
Audio streaming	Two-way
Audio Compression	AAC-LC 8/16/32 kHz
Audio Input / Output	External balanced/unbalanced microphone or line input, line output
Security	Password protection, IP address filtering, HTTPSc encryption, IEEE 802.1Xc network access control, Digest authentication, User access log
Protocol Support	IPv4/v6, HTTP, HTTPSc , SSL/TLSc , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Application Programming Interface	Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www.axis.com. AXIS Video Hosting System (AVHS) with One-Click Camera Connection ONVIF Profile S; specification available at www.onvif.org
Intelligent Video	Video motion detection, Active tampering alarm, Audio detection, Support for AXIS Camera Application Platform enabling installation of AXIS Video Motion Detection 3, AXIS Cross Line Detection, AXIS Digital Autotracking and third-party applications, see www.axis.com/acap
Trigger Events	Shock detection
Event actions	File upload: FTP, HTTP, HTTPS, network share and email Send video clip Notification: email, HTTP, HTTPS and TCP Overlay text, Send SNMP Trap Video and audio recording to edge storage Pre- and post-alarm video buffering External output activation, Day/night vision mode, Play audio clip, Status LED, WDR mode
Data streaming	Event data
Casing	Camera: Metal (zinc)
Memory	256 MB RAM, 128 MB Flash
Power	8–28 V DC or Power over Ethernet IEEE 802.3af/802.3at Type 1 Class 3 max. 10.8 W
Connectors	Terminal block for 1 alarm input and 1 output RS485/RS422, Terminal block for two configurable inputs/outputs (12 V DC output, max. load 50 mA)
Edge Storage	microSD/microSDHC/microSDXC slot supporting memory card up to 64 GB (card not included)
Operating Conditions	0 °C to 50 °C (32 °F to 122 °F)
Approvals	KCC KN22 Class B, KN24
Weight	925 g (2 lb)
Included accessories	Stand, Connector kit, Resistorx T20 tool, Installation Guide, Installation and Management Software CD, Windows decoder 1-user license
Video Management Software	AXIS Camera Station and video management software from Axis’ Application Development Partners (not included). For more information, see: www.axis.com/products/video/software
