Image Sensor
|
Progressive scan RGB CMOS 1/2.8” |
Lens
|
Varifocal, 3.0-10.5 mm, F1.4 Horizontal angle of view: 95°-34° Vertical angle of view: 49°-20° Remote focus and zoom, P-Iris control, IR corrected |
Day/Night
|
Automatically removable infrared-cut filter |
Min.Illumination
|
Color: 0.25 lux, F1.4 B/W: 0.05 lux, F1.4 |
Shutter Time
|
1/33500 s to 2 s |
Angle Adjustment
|
Pan ±180°, Tilt 90°, Rotation ±95° |
Video Compression
|
H.264 (MPEG-4 Part 10/AVC) Baseline, Main and Baseline Profile Motion JPEG |
Video Resolution
|
1920x1080 to 160x90 |
Video Framerate
|
Up to 25/30 fps with power line frequency 50/60 Hz in all resolutions |
Video Streaming
|
Multiple, individually configurable streams in H.264 and Motion JPEG Controllable frame rate and bandwidth, VBR/MBR H.264 |
Multi-view streaming
|
2 individually cropped out view areas |
Image settings
|
Compression, Color, Brightness, Sharpness, Contrast, White balance, Exposure control (including automatic gain control), Exposure zones, Backlight compensation, Fine tuning of behavior at different light levels, WDR - Dynamic Contrast, Text and image overlay, Mirroring of images, Privacy mask Rotation: 0°, 90°, 180°, 270°, including Corridor Format |
Pan/ Tilt/ Zoom
|
Digital PTZ |
Security
|
Password protection, IP address filtering, HTTPSa encryption, IEEE 802.1Xa network access control, Digest authentication, User access log, Centralized Certificate Management |
Protocol Support
|
IPv4/v6, HTTP, HTTPSa , SSL/TLSa , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMP v1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SFTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH |
Application Programming Interface
|
Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www.axis.com AXIS Video Hosting System (AVHS) with One-Click Connection ONVIF Profile S, specification at www.onvif.org |
Analytics
|
Video motion detection, Active tampering alarm Support for AXIS Camera Application Platform enabling installation of AXIS Video Motion Detection 3, AXIS Cross Line Detection, AXIS Digital Autotracking and third-party applications, see www.axis.com/acap |
Trigger Events
|
Analytics, Edge storage events |
Event actions
|
File upload: FTP, SFTP, HTTP, HTTPS, network share and email Notification: email, HTTP, HTTPS, TCP and SNMP trap Video recording to edge storage Pre- and post-alarm video buffering Send video clip Overlay text |
Data streaming
|
Event data |
Built-in installation aids
|
Remote zoom, Remote focus, Pixel counter |
Casing
|
Aluminum inner camera module with encapsulated electronics IK08 impact-resistant, dust-resistant, polycarbonate casing with dehumidifying membrane Color: White NCS S 1002-B For repainting instructions of skin cover or casing and impact on warranty, contact your Axis partner. |
Memory
|
256 MB RAM, 128 MB Flash |
Power
|
Power over Ethernet IEEE 802.3af/802.3at Type 1 Class 2 Max 4.8 W, Typical 3.5 W |
Connectors
|
RJ45 10BASE-T/100BASE-TX PoE |
Edge Storage
|
Support for microSD/microSDHC/microSDXC card Support for recording to dedicated network-attached storage (NAS) For SD card and NAS recommendations see www.axis.com |
Operating Conditions
|
0 °C to 50 °C (32 °F to 122 °F) Humidity 10 to 85% RH (non-condensing) |
Storage Temperature
|
-40 °C to 65 °C (-40 °F to 149 °F) |
Approvals
|
55022 Class B, EN 61000-6-1, EN 61000-6-2, EN 55024, EN 50121-4, IEC 62236-4, FCC Part 15 Subpart B Class A+B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22 Class B, IEC/EN/UL 60950-1, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP42, IEC/EN 62262 IK08 |
Weight
|
550 g (1.2 lb) |
Dimension
|
101 x 149 x 149 mm (4.0 x 5.9 x 5.9 in) |
Included accessories
|
Installation Guide, Windows decoder 1-user license, Mounting bracket, Cable gasket, Resistorx T20 L-key, Drill template |
Optional accessories
|
AXIS T90B Illuminators AXIS ACI Conduit Bracket B AXIS T94S01S Mounting Bracket AXIS ACI Conduit Adapters AXIS T94K01L Recessed Mount AXIS T94K01D Pendant Kit AXIS Skin Cover C, Black |
Video Management Software
|
AXIS Camera Companion, AXIS Camera Station, Video management software from Axis’ Application Development Partners available on www.axis.com/techsup/software |
Language
|
German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese |
