Image Sensor
|
Progressive scan RGB CMOS 1/2.8” |
Lens
|
P-Iris Varifocal 2.8–8 mm: 80°–39° viewa , F1.2 |
Day/Night
|
Automatically removable infrared-cut filter |
Min.Illumination
|
Color: 0.2 lux, F1.2, B/W: 0.04 lux, F1.2 |
Shutter Time
|
Power line frequency 50 Hz: 1/28000 s to 2 s Power line frequency 60 Hz: 1/33500 s to 2 s |
Video Compression
|
H.264 (MPEG-4 Part 10/AVC), H.264 Baseline and Main Profile, Motion JPEG |
Video Resolution
|
1920x1080 (HDTV) to 160x90 |
Video Framerate
|
25/30 fps in 50/60 Hz power line frequency |
Video Streaming
|
Multiple, individually configurable streams in H.264 and Motion JPEG, Controllable frame rate and bandwidth, VBR/CBR H.264 |
Multi-view streaming
|
Up to 8 individually cropped out view areas |
Image settings
|
Compression, Color, Brightness, Sharpness, Contrast, White balance, Exposure control, Exposure zones, Backlight compensation, Fine tuning of behavior at low light, WDR - dynamic contrast Text and image overlay, Privacy mask, Mirroring of images |
Audio streaming
|
Two-way, full duplex |
Audio Compression
|
AAC LC 8/16 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz Configurable bit rate |
Audio Input / Output
|
External microphone input or line input, line output |
Security
|
Password protection, IP address filtering, HTTPSc encryption, IEEE 802.1Xc network access control, Digest authentication, User access log |
Protocol Support
|
IPv4/v6, HTTP, HTTPSc , SSL/TLSc , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP™, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS |
Application Programming Interface
|
Open API for software integration, including VAPIX® and AXIS Camera Application Platform, specifications at www.axis.com AXIS Video Hosting System (AVHS) with One-Click Camera Connection ONVIF Profile S, specification at www.onvif.org Support for AXIS Camera Companion |
Intelligent Video
|
Video motion detection, Active tampering alarm, Audio detection, AXIS Camera Application Platform enabling installation of additional applications |
Trigger Events
|
Intelligent video, Edge storage events, External input, Audio level, Time scheduled |
Event actions
|
File upload: FTP, HTTP, Network share and email Notification: email, HTTP and TCP Video and audio recording to edge storage Pre- and post-alarm video buffering PTZ preset, Guard tour External output activation Play audio clip, Day/Night switching, Status LED activation |
Data streaming
|
Event data |
Built-in installation aids
|
Focus assistant, Pixel counter, Remote back focus |
Casing
|
IP66- and NEMA 4X-rated, IK10 impact resistant aluminum enclosure Color: White NCS S 1002-B |
Memory
|
256 MB RAM, 128 MB Flash |
Power
|
Power over Ethernet (PoE) IEEE 802.3af max. 12.95 W or High PoE max. 25.5 W |
Connectors
|
P-Iris connector (compatible with DC-iris) |
Edge Storage
|
MicroSD/microSDHC slot supporting memory card up to 64 GB (card not included) Support for recording to network share (network-attached storage or file server) |
Operating Conditions
|
-30 °C to 50 °C (-22 °F to 122 °F) with PoE, down to -40 °C (-40 °F) with High PoE Humidity 10–100% RH (condensing) |
Approvals
|
EN 50121-4/IEC 62236, IEC/EN/UL 60950-22, IEC/EN 60529 IP66, NEMA 250 Type 4X, IEC 60068-2-6, IEC 60068-2-27, IEC/EN 62262 IK10 |
Weight
|
3.1 kg (6.8 lb) |
Included accessories
|
Wall mount bracket, Sunshield, Connector kit, Installation Guide, Windows decoder 1-user license, Installation and Management Software CD |
