Camera
|
| Image Sensor |
5MP CMOS Image Sensor |
| Effective Pixels |
2592(H)x1944(V) |
| Audio Out |
1-ch BNC Output |
| Minimum Illumination |
0.01 Lux @ (F1.2,AGC ON),0 Lux with IR |
| Shutter Time |
1/12.5 s to 1/20,000 s |
| Lens |
1.1mm |
| Lens Mount |
M12 |
| Adjustment Range |
Pan: 0 - 360°, Tilt: 0°, Rotation: 0° |
| Day& Night |
ICR |
| Video Frame Rate |
SMP @12.5fps |
| HD Video Output |
1-ch bnc output |
| Synchronization |
Internal Synchronization |
| Audio IN |
Built in Mic |
|
Menu
|
| Mounting Type |
Ceiling/wall |
| Ceiling Mounting Display Mode |
Default, Panorama, 4ptz, Fisheye&3ptz, Annular, Mini-fisheye &1ptz, Annular & 2ptz |
| Wall Mounting Display Mode |
Default, Panorama, 4ptz, Fisheye&3ptz, Panorama & 3ptz |
| D/N Mode |
Color/BW/Auto |
| Function |
Brightness, Contrast, Saturation, Sharpness |
|
General
|
| Operating Conditions |
-20 °C - 60 °C (-4 °F - 140 °F)
Humidity 90% or less (non-condensing) |
| Power Supply |
DC12 VDC±15% |
| Power Consumption |
Max. 5.5W |
| IR Range |
10-20mm |
| Communication |
Up the coax
Protocol: HIKVISION-C(Coaxitron) |
| Dimension |
φ120.4mm×54.5mm (φ4.74”×2.14”) |
| Weight |
Approx. 350g |
| Weather Proof |
IP66 |
