Camera
|
| Image Sensor |
1/3" Progressive Scan CMOS |
| Effective Pixels |
1280(H)x720(V) |
| Signal System |
PAL/NTSC |
| Minimum Illumination |
Color: 0.05Lux@( F1.4,AGC ON); B/W: 0.005Lux@( F1.4,AGC ON), 0 Lux with IR |
| White Balance |
Auto/Manual/ATW/Indoor/Outdoor |
| AGC |
Auto/Manual |
| BLC |
ON/OFF |
| WDR |
Support |
| Shutter Time |
PAL: 1-1/10,000s
NTSC: 1-1/10,000s |
| Day& Night |
ICR |
| Digital Zoom |
16X |
| Privacy Masking |
8 privacy masks programmable |
| Auto Focus |
Auto / Semi-automatic / Manual |
|
Input/Output
|
| Turbo HD Output |
1 turbo HD720P/1080P Output, 1.0V(p-p) 750, NTSC(or PAL) composite. BNC |
| CBVS Output |
1.0V(p-p)/75, NTSC(or PAL)composite, BNC |
| RS-485 Interface |
Half Duplex Mode, Self Adaptive Hikvision, Pelco-P, Pelco-D Protocol |
| UTC Function |
Hikvision_C |
|
Pan and Tilt
|
| Range |
360°endless |
| Speed |
Pan Manual Speed: 0.1°~80°/s, Pan Preset Speed: 80°/s |
| Tilt Range |
-15°~90° (auto flip) |
| Tilt Speed |
Tilt Manual Speed: 0.1°~80°/s, Tilt Preset Speed: 80°/s |
| Proportional Zoom |
Rotation speed can be adjusted automatically according to zoom multiples |
| Number of Preset |
256 |
| Patrol |
8 patrols, up to 32 presets per patrol |
| Pattern |
4 patterns, with the recording time not less than 10 minutes per pattern |
| Power loss recovery |
Support |
| Park Action |
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan |
| PTZ Position Display |
ON/OFF |
| Freeze Frame |
Support |
|
Infrared
|
| IR irradiation distance |
100m |
| IR irradiation Angle |
Adjustable by Distance, Depending On Zoom ratio |
|
General
|
| Menu Language |
English |
| Power |
12VDC, Max 18 Watt |
| Working Temp/Humidity |
-30°C ~ 65°C (-22°F ~ 149°F)
90% or less |
| Protection Level |
IP66 standard (outdoor dome)
TVS 4,000V lightning protection, surge protection and voltage transient protection |
| Dimensions |
Φ164.5×295mm (Φ7.28”×12.99”) |
| Weight (approx.) |
2Kg(4.41Ibs) |
| Mount Option |
Long-arm wall mount: DS-1602ZJ; Corner mount: DS-1602ZJ-corner; Pole Mount: DS-1602ZJ-pole;
Power box mount:DS-1602ZJ-box;Swan-neck mount: DS-1619ZJ |
