DAHUA IPC-HDW1320S

Rp 1.689.000

tidak termasuk pengiriman

• 1/3” 3Megapixel progressive CMOS
• H.264+ & H.264 dual-stream encoding
• 20fps@3M(2048x1536)&25/30fps@1080P(1920×1080)
• DWDR, Day/Night(ICR), 3DNR, AWB, AGC, BLC
• Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
• 2.8 mm fixed lens (3.6 mm optional)
• Max IR LEDs length 30m
• IP67, PoE

Qty:

Overview
Contact Us

Jual IP Camera DAHUA IPC-HDW1320S dengan harga murah, kompetitif dan terjangkau di JakartaCCTV. IP Kamera turret DAHUA seri Lite yang terlindungi dalam casing weatherproof IP67 ini menggunakan lensa 2.8mm (atau opsi lain 3.6mm) yang dikombinasikan dengan jangkauan infra merah sejauh 30 meter serta Dahua’s unique Smart IR yang dapat menyesuaikan intensitas dari cahaya infra merah untuk menangkap gambar & video dengan resolusi hingga 3MP pada kondisi rendah cahaya sekalipun.

Pengguna yang memutuskan untuk menempatkan kamera ini di area indoor tidak akan kecewa oleh performanya karena kamera ini juga dilengkapi dengan Filter IR Cut mekanik True Day/Night yang dapat menampilkan image berwarna pada siang hari dan secara otomatis beralih ke image monochrome pada saat suasana berangsur gelap,Teknologi 3D DNR (yang bisa mengeliminasi gangguan pada gambar seperti gambar yang blur pada saat objek bergerak atau pada saat mengambil video pada kondisi pencahayaan yang rendah dengan menganalisa single frame pada gambar secara individu untuk membedakan pixel yang mungkin mengganggu, & di saat yang bersamaan mengurangi tempat penyimpanan HDD yang diperlukan untuk perekaman DVR), dan berbagai fitur cerdik lainnya. Selain itu kamera ini juga mendukung PoE serta kepatuhan pada spesifikasi ONVIF (Open Network Video Interface Forum), yang memastikan kamera ini dapat berinteraksi dan berfungsi dengan produk network video dari pabrikan lainnya.

FITUR & FUNGSI DAHUA IPC-HDW1320S

1/3” 3Megapixel progressive CMOS
H.264+ & H.264 dual-stream encoding
20fps@3M(2048x1536)&25/30fps@1080P(1920×1080)
DWDR, Day/Night(ICR), 3DNR, AWB, AGC, BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
2.8 mm fixed lens (3.6 mm optional)
Max IR LEDs length 30m
IP67, PoE

Hubungi kami sekarang untuk mendapatkan penawaran terbaik dengan harga distributor yang murah untuk IP Cam DAHUA IPC-HDW1320S ini yang disertai dengan garansi resmi 2 tahun dari distributor DAHUA di Indonesia. Kami, JakartaCCTV akan dengan senang hati membimbing dan membantu anda memilih IP Kamera DAHUA atau paket CCTV lainnya yang paling cocok untuk kebutuhan anda hingga proses pasang & setting nya.

Camera
Image Sensor	1/3” 3Megapixel progressive CMOS
Effective Pixels	2304(H) x1536(V)
RAM/ROM	256MB/16MB
Scanning System	Progressive
Electronic Shutter Speed	Auto/Manual, 1/3(4)~1/100000s
Minimum Illumination	0.1Lux/F2.0(Color), 0Lux/F2.0(IR on)
S/N Ratio	More than 50dB
IR Distance	Distance up to 30m(98ft)
IR On/Off Control	Auto/ Manual
IR LEDs	18
Lens
Lens Type	Fixed
Mount Type	Board-in
Focal Length	2.8 mm (3.6 mm optional)
Max. Aperture	F2.0/F2.0
Angle of View	H:98°/77°,V:51°/40.5°
Focus Control	Fixed
Close Focus Distance	N/A
DORI Distance	Lens 2.8 mm Detect 58m(190ft) Observe 23m(75ft) Recognize 12m(39ft) Identify 6m(20ft) Lens 3.6 mm Detect 73m(240ft) Observe 29m(95ft) Recognize 15m(49ft) Identify 7m(23ft)
PTZ
Pan/Tilt Range	Pan:0° ~360 ° ;Tilt:0° ~90° ;Rotation:0° ~360°
Video
Compression	H.264+/H.264
Streaming Capability	2 Streams
Resolution	3M(2304×1296)(2048×1536)/1080P(1920x1080)/1.3M(1280x960)/ 720P(1280×720)/D1(704×576/704×480)/ CIF(352×288/352×240)
Frame Rate	3M(1 ~ 20fps)/2M (1 ~ 25/30fps)s) D1/CIF(1 ~ 25/30fps)
Bit Rate Control	CBR/VBR
Bit Rate	H264:24K ~ 8192Kbps
Day/Night	Auto(ICR) / Color / B/W
BLC Mode	BLC / HLC / DWDR
White Balance	Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control	Auto/Manual
Noise Reduction	3D DNR
Motion Detetion	Off / On (4 Zone, Rectangle)
Region of Interest	Off / On (4 Zone)
Electronic Image	Support
Smart IR	Support
Digital Zoom	16x
Flip	0°/90°/180°/270°
Mirror	Off / On
Privacy Masking	Off / On (4 Area, Rectangle)
Audio
Compression	N/A
Network
Ethernet	RJ-45 (10/100Base-T)
Protocol	HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP; DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP;NTP; Bonjour;802.1x;Multicast;ICMP;IGMP;
Interoperability	ONVIF, PSIA, CGI
Streaming Method	Unicast / Multicast
Max. User Access	10 Users/20 Users
Edge Storage	NAS(Network Attached Storage) Local PC for instant recording
Web Viewer	IE, Chrome, Firefox, Safari
Management Software	Smart PSS, DSS,Easy4ip
Smart Phone	iPhone, iPad, Android Phone
Certifications
Certifications	CE (EN 60950:2000) UL:UL60950-1 FCC: FCC Part 15 Subpart B
Interface
Video Interface	N/A
Audio Interface	N/A
RS485	N/A
Alarm	N/A
Electrical
Power Supply	DC12V PoE (802.3af)(Class 0)
Power Consumption	<6.4W
Environmental
Operating Conditions	-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Strorage Conditions	-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Ingress Protection	IP67
Vandal Resistance	N/A
Construction
Casing	Metal+Plastic
Dimensions	Φ108mm×84.9mm(4.25'x3.15')
Net Weight	0.23Kg(0.51lb)
Gross Weight	0.387Kg(0.85lb)
