Camera |
|
Image Sensor |
1/3” 3Megapixel progressive CMOS |
Effective Pixels |
2304(H) x1536(V) |
RAM/ROM |
256MB/16MB |
Scanning System |
Progressive |
Electronic Shutter Speed |
Auto/Manual, 1/3(4)~1/100000s |
Minimum Illumination |
0.1Lux/F2.0(Color), 0Lux/F2.0(IR on) |
S/N Ratio |
More than 50dB |
IR Distance |
Distance up to 30m(98ft) |
IR On/Off Control |
Auto/ Manual |
IR LEDs |
24 |
Lens |
|
Lens Type |
Fixed |
Mount Type |
Board-in |
Focal Length |
2.8 mm (3.6 mm optional) |
Max. Aperture |
F2.0/F2.0 |
Angle of View |
H:98°/77°, V:51°/41° |
Focus Control |
Fixed |
Close Focus Distance |
N/A |
DORI Distance |
Lens 2.8 mm Detect 58m(190ft) Observe 23m(75ft) Recognize 12m(39ft) Identify 6m(20ft) Lens 3.6 mm Detect 73m(240ft) Observe 29m(95ft) Recognize 15m(49ft) Identify 7m(23ft) |
PTZ |
|
Pan/Tilt Range |
Pan:0° ~355° ;Tilt:0° ~65° ;Rotation:0° ~355° |
Video |
|
Compression |
H.264+/H.264 |
Streaming Capability |
2 Streams |
Resolution |
3M(2304×1296)(2048×1536)/1080P(1920x1080)/1.3M(1280x960)/ 720P(1280×720)/D1(704×576/704×480)/ CIF(352×288/352×240) |
Frame Rate |
3M(1 ~ 20fps)/2M (1 ~ 25/30fps)s) D1/CIF(1 ~ 25/30fps) |
Bit Rate Control |
CBR/VBR |
Bit Rate |
H264:24K ~ 8192Kbps |
Day/Night |
Auto(ICR) / Color / B/W |
BLC Mode |
BLC / HLC / DWDR |
White Balance |
Auto/Natural/Street Lamp/Outdoor/Manual |
Gain Control |
Auto/Manual |
Noise Reduction |
3D DNR |
Motion Detetion |
Off / On (4 Zone, Rectangle) |
Region of Interest |
Off / On (4 Zone) |
Electronic Image |
Support |
Smart IR |
Support |
Digital Zoom |
16x |
Flip |
0°/90°/180°/270° |
Mirror |
Off / On |
Privacy Masking |
Off / On (4 Area, Rectangle) |
Audio |
|
Compression |
N/A |
Network |
|
Ethernet |
RJ-45 (10/100Base-T) |
Protocol |
HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP; DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP;NTP; Bonjour;802.1x;Multicast;ICMP;IGMP; |
Interoperability |
ONVIF, PSIA, CGI |
Streaming Method |
Unicast / Multicast |
Max. User Access |
10 Users/20 Users |
Edge Storage |
NAS(Network Attached Storage) Local PC for instant recording |
Web Viewer |
IE, Chrome, Firefox, Safari |
Management Software |
Smart PSS, DSS,Easy4ip |
Smart Phone |
iPhone, iPad, Android Phone |
Certifications |
|
Certifications |
CE (EN 60950:2000) UL:UL60950-1 FCC: FCC Part 15 Subpart B |
Interface |
|
Video Interface |
N/A |
Audio Interface |
N/A |
RS485 |
N/A |
Alarm |
N/A |
Electrical |
|
Power Supply |
DC12V PoE (802.3af)(Class 0) |
Power Consumption |
<5.0W |
Environmental |
|
Operating Conditions |
-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH |
Strorage Conditions |
-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH |
Ingress Protection |
IP67 |
Vandal Resistance |
IK10 |
Construction |
|
Casing |
Metal |
Dimensions |
Φ109.9mm × 81mm (4.33" x 3.19") |
Net Weight |
0.34Kg (0.75lb) |
Gross Weight |
0.47Kg (1.04lb) |
