System |
|
Main Processor |
Embedded Processor |
Operating System |
Embedded LINUX |
Video |
|
Input |
8 channel, BNC |
Standard |
HDCVI : 1080P/720P HDCVI Camera Analog : NTSC/PAL IP : Support 2ch 1080P/720P IP Camera |
Audio |
|
Input |
8 channel, BNC |
Output |
1 channel, BNC |
Two-way Talk |
1 channel Input, 1 channel Output, BNC |
Display |
|
Interface |
1 HDMI, 1 VGA ,1 TV |
Resolution |
1920× 1080, 1280× 1024, 1280× 720, 1024× 768 |
Display Split |
1/4/8/9 |
Privacy Masking |
4 rectangular zones (each camera) |
OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
Recording |
|
Video/Audio Compression |
H.264/G.711 |
Record Rate |
Main Stream : 1080P(1~12/15fps)/720P/960H/D1/HD1/2CIF/CIF(1~25/30fps) Extra Stream : CIF/QCIF(1~25/30fps) |
Bit Rate |
48~4096Kb/s |
Record Mode |
Manual, Schedule(Regular(Continuous), MD), Stop |
Record Interval |
1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
Video Detection |
|
Trigger Events |
Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips |
Video Detection |
Motion Detection, MD Zones: 396(22× 18), Video Loss & Camera Blank |
Alarm Input |
8 channel |
Relay Output |
6 channel |
Playback & Backup |
|
Sync Playback |
1/4/9 |
Search Mode |
Time/Date, MD & Exact search (accurate to second) |
Playback Functions |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
Backup Mode |
USB Device/eSATA Device/Internal SATA burner/Network |
Network |
|
Ethernet |
2RJ-45 port (10/100M/1000M) |
Network Functions |
HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, SNMP, P2P |
Max. User Access |
128 users |
Smart Phone |
iPhone, iPad, Android, Windows Phone |
Storage |
|
Internal HDD |
8 SATA ports(8HDDs or 6HDDs+1CD/DVD-RW), up to 32TB |
External HDD |
1 eSATA port |
Auxiliary Interface |
|
USB Interface |
4 ports (2 Rear), USB2.0 |
RS232 |
1 port, For PC communication & Keyboard |
RS485 |
1 port RS485 for PTZ control,1 port RS422 for Keyboard |
General |
|
Power Supply |
AC 100~240 V, 50/60 Hz |
Power Consumption |
40W (Without HDD) |
Working Environment |
-10°C~+55°C / 10%~90%RH / 86~106kpa |
Dimension (W× D× H) |
2U, 440mm×460mm×89mm |
Weight |
6.5KG(without HDD) |
