System |
|
Main Processor |
Embedded Processor |
Operating System |
Embedded LINUX |
Display |
|
Interface |
1 HDMI ,1 VGA |
Resolution |
1920×1080, 1280×1024, 1280×720, 1024×768 |
Multi-screen Display |
1/4/6 |
OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
Video Detection and Alarm |
|
Trigger Events |
Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
Video Detection |
Motion Detection, MD Zones: 396 (22 × 18), Video Loss,Tampering and Diagnosis |
Alarm input |
N/A |
Relay Output |
N/A |
Playback and Backup |
|
Playback |
1/4 |
Search Mode |
Time /Date, Alarm, MD and Exact Search (accurate to second) |
Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
Backup Mode |
USB Device/Network |
Storage |
|
Internal HDD |
1 SATA Port, up to 8TB capacity |
eSATA |
N/A |
Auxiliary Interface |
|
USB |
2 USB Ports (2 USB 2.0) |
RS232 |
N/A |
RS485 |
1 Port, for PTZ Control |
HDCVI Camera Input |
4 Channel |
IP Camera Input |
4+2 Channel, each channel up to 5MP |
Audio In/Out |
1/1, RCA |
Two-way Talk |
Reuse audio in/out, RCA |
Recording |
|
Compression |
H.264+/H.264 |
Resolution |
1080P, 1080N, 720P, 960H, D1, HD1, BCIF, CIF, QCIF |
Record Rate |
Main Stream: 1080P(1~15fps), 1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF (1~25/30fps) Sub stream : D1/CIF/QCIF(1~15fps) |
Bit Rate |
1Kbps ~ 6144Kbps Per Channel |
Record Mode |
Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop |
Record Interval |
1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec |
Network |
|
Interface |
1 RJ-45 Port (100M) |
Network Function |
HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search (Support Dahua IP camera, DVR, NVS, etc.) |
Max. User Access |
128 users |
Smart Phone |
iPhone, iPad, Android |
Interoperability |
ONVIF 2.42, CGI Conformant |
Electrical |
|
Power Supply |
DC12V/2A |
Power Consumption |
<15W (Without HDD) |
Environmental |
|
Operating Conditions |
-10°C ~ +55°C (+14°F ~ +131°F), 0~ 90% RH |
Storage Conditions |
-20°C ~ +70°C (-4°F ~ +158°F) , 0~ 90% RH |
Construction |
|
Dimensions |
Compact 1U, 260×236×48mm(10.2"×9.3"×1.9") |
Net Weight |
0.75kg ( 1.7lb) (without HDD) |
Gross Weight |
1.5kg (3.3lb) |
Installation |
Desktop installation |
Certifications |
|
Certifications |
FCC: Part 15 Subpart B ICES 003 Issue 6 CE: EN 55032: 2012+AC:2013 (Class B) EN 55024 : 2010 EN 61000-3-2 : 2014 EN 50130-4: 2011 EN 61000-3-3 : 2013 UL 60950-1 and CAN/CSA C22.2 No. 60950-1-07 |
