Image Sensor
|
Progressive scan RGB CMOS 1/2.9” |
|
Lens
|
4.7–84.6 mm, F1.6–2.8 Horizontal field of view 59°–4° V ertical field of view 35°–2° Autofocus |
|
Day/Night
|
Automatically removable infrared-cut filter |
|
Minimum Ilumination
|
Color: 0.5 lux at 30 IRE F1.6 B/W: 0.04 lux at 30 IRE F1.6 |
|
Shutter Time
|
1/28000 s to 2 s |
|
Pant/Tilt/Zoom
|
18x optical zoom and 12x digital zoom, total 2 16x zoom 64 preset positions |
|
Video
|
H.264 (MPEG - 4 P art 1 0/A VC) Baseline, and Main profiles Motion JPEG |
|
Resolution
|
1920x1 080 HD TV 1 080p to 160x90 |
|
Frame Rate
|
Up to 30/25 fps (60/50 Hz) in all resolutions |
|
Video Streaming
|
Multiple, individually configurable streams in H.264 and Motion JPEG Controllable frame rate and bandwidth VBR/CBR H.264 |
|
Image settings
|
Compression, color , brightness, sharpness, white balance, exposure control, exposure zones, backlight compensation, WDR – dynamic contrast, fine tuning of behavior at low light, rotation, text and image overlay , day/night shift level |
|
Security
|
P assword protection, IP address filtering, HTTPS a encryption, Digest authentication, User access log, Centralized Certificate Management |
|
Supported Protocols
|
IPv4/v6, HTTP , HTTPS a , SSL/TLS a , QoS Layer 3 DiffServ , FTP , SFTP , CIFS/SMB, SMTP , Bonjour , UPnP T M , SNMP v1/v2c/v3 (MIB - II), DNS, DynDNS, NTP , RTSP , RTP , T CP , UDP , IGMP , RT CP , ICMP , DHCP , ARP , SOCKS, SSH |
|
Aplication Programming Interface
|
Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www .axis.com AXIS Video Hosting System (A VHS) with One - Click Connection ONVIF® Profile S and ONVIF® Profile G, specification at www .onvif.org |
|
Analytics
|
AXIS Video Motion Detection 4, active tampering alarm Support for AXIS Camera Application Platform enabling installation of third - party applications, see www .axis.com/acap |
|
Event Triggers
|
Analytics, Edge storage events |
|
Event actions
|
File upload: FTP, HTTP, network share and email Notification: email, HTTP and TCP Pre- and post-alarm video buffering |
|
Data streaming
|
Event data |
|
Built-in installation aids
|
Pixel counter |
|
Casing
|
IP66 - and IP67 - rated, electropolished SAE 3 16L stainless steel casing for maximum corrosion protection |
|
Memory
|
256 MB RAM, 128 MB Flash |
|
Power
|
24 Volt |
|
Connectors
|
XF40 - Q1765 models: Three M20 conduit entries XF40 - Q1765 UL models: Three 3/4" NPT conduit entires |
|
Storage
|
Support for microSD/microSDHC/microSDXC card Support for SD card encryption Support for recording to network - attached storage (NAS) For SD card and NAS recommendations see www .axis.com |
|
Operation condition
|
XF40 - Q1765: - 40 °C to 7 0 °C ( - 40 °F to 158 °F) XF40 - Q1765 - 60 C: - 60 °C to 40 °C ( - 76 °F to 1 04 °F) XF40 - Q1765 - 50 C UL: - 50 °C to 7 0 °C ( - 58 °F to 158 °F) Humidity 1 0–1 00% RH (condensing) |
