    AXIS XF40-Q1765-60 INMETRO

    Telp untuk Harga
    * Certified for hazardous areas by Oxalis Group Ltd. by Eatonr
    * Electro-polished 316L stainless steel housingr
    * Full HDTV 1080p resolutionr
    * 18x zoom and autofocusr
    * Two product versions, depending on temperature range neededr
    * Wide Dynamic Ranger
    * Explosion-protected 316L stainless steel fixed network camera certified for hazardous areas according to cLCus.r
    * Certification part code 1410-15-00.r
    * Oxalis housing with 3/4" NPT,r
    * Axis 1080p HDTV camera with 18x optical zoom,r
    * Auto focus and day/night mode. Multiple,r
    * Individually configurable H.264 and Motion JPEG streams;r
    * Max HDTV 1080p resolution at 25/30 fps.r
    * WDR- dynamic contrast. Video motion detection and active tampering alarm.r
    * IP66 and IP67-rated and operating temperature in -60°C to +40°C ( -76ºF to +104ºF).r
    * Powered by 24 V AC (Power supply not included).r
    * Includes a removable sunshield.r

    AXIS XF40-Q1765-60 INMETRO

    XF40-Q1765 Explosion Protected Fixed Network Camera is suitable for onshore, offshore, marine and heavy industrial environments. It features a 316L stainless steel housing certified for hazardous areas according to for example ATEX and IECEx. The housing prevents any inside sparks or explosions from escaping and igniting vapors, gases, dust or fibers in the surrounding air. XF40-Q1765 provides superb image quality and color fidelity and a high level of flexible integration with other equipment, such as access control and fire alarms. It offers flexible remote accessibility, using any existing IP-based networks. XF40-Q1765 for hazardous areas is a complement to Axis’ wide range of network cameras that can be used in safe areas.

    Spesifikasi produk
    Image Sensor Progressive scan RGB CMOS 1/2.9”
    Lens 4.7–84.6 mm, F1.6–2.8 Horizontal field of view 59°–4° V ertical field of view 35°–2° Autofocus
    Day/Night Automatically removable infrared-cut filter
    Minimum Ilumination Color: 0.5 lux at 30 IRE F1.6 B/W: 0.04 lux at 30 IRE F1.6
    Shutter Time 1/28000 s to 2 s
    Pant/Tilt/Zoom 18x optical zoom and 12x digital zoom, total 2 16x zoom 64 preset positions
    Video H.264 (MPEG - 4 P art 1 0/A VC) Baseline, and Main profiles Motion JPEG
    Resolution 1920x1 080 HD TV 1 080p to 160x90
    Frame Rate Up to 30/25 fps (60/50 Hz) in all resolutions
    Video Streaming Multiple, individually configurable streams in H.264 and Motion JPEG Controllable frame rate and bandwidth VBR/CBR H.264
    Image settings Compression, color , brightness, sharpness, white balance, exposure control, exposure zones, backlight compensation, WDR – dynamic contrast, fine tuning of behavior at low light, rotation, text and image overlay , day/night shift level
    Security P assword protection, IP address filtering, HTTPS a encryption, Digest authentication, User access log, Centralized Certificate Management
    Supported Protocols IPv4/v6, HTTP , HTTPS a , SSL/TLS a , QoS Layer 3 DiffServ , FTP , SFTP , CIFS/SMB, SMTP , Bonjour , UPnP T M , SNMP v1/v2c/v3 (MIB - II), DNS, DynDNS, NTP , RTSP , RTP , T CP , UDP , IGMP , RT CP , ICMP , DHCP , ARP , SOCKS, SSH
    Aplication Programming Interface Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www .axis.com AXIS Video Hosting System (A VHS) with One - Click Connection ONVIF® Profile S and ONVIF® Profile G, specification at www .onvif.org
    Analytics AXIS Video Motion Detection 4, active tampering alarm Support for AXIS Camera Application Platform enabling installation of third - party applications, see www .axis.com/acap
    Event Triggers Analytics, Edge storage events
    Event actions File upload: FTP, HTTP, network share and email Notification: email, HTTP and TCP Pre- and post-alarm video buffering
    Data streaming Event data
    Built-in installation aids Pixel counter
    Casing IP66 - and IP67 - rated, electropolished SAE 3 16L stainless steel casing for maximum corrosion protection
    Memory 256 MB RAM, 128 MB Flash
    Power 24 Volt
    Connectors XF40 - Q1765 models: Three M20 conduit entries XF40 - Q1765 UL models: Three 3/4" NPT conduit entires
    Storage Support for microSD/microSDHC/microSDXC card Support for SD card encryption Support for recording to network - attached storage (NAS) For SD card and NAS recommendations see www .axis.com
    Operation condition XF40 - Q1765: - 40 °C to 7 0 °C ( - 40 °F to 158 °F) XF40 - Q1765 - 60 C: - 60 °C to 40 °C ( - 76 °F to 1 04 °F) XF40 - Q1765 - 50 C UL: - 50 °C to 7 0 °C ( - 58 °F to 158 °F) Humidity 1 0–1 00% RH (condensing)
    *
    *
    *

    AXIS XF40-Q1765-60 INMETRO

    XF40-Q1765 Explosion Protected Fixed Network Camera is suitable for onshore, offshore, marine and heavy industrial environments. It features a 316L stainless steel housing certified for hazardous areas according to for example ATEX and IECEx. The housing prevents any inside sparks or explosions from escaping and igniting vapors, gases, dust or fibers in the surrounding air. XF40-Q1765 provides superb image quality and color fidelity and a high level of flexible integration with other equipment, such as access control and fire alarms. It offers flexible remote accessibility, using any existing IP-based networks. XF40-Q1765 for hazardous areas is a complement to Axis’ wide range of network cameras that can be used in safe areas.

    Spesifikasi produk
    Image Sensor Progressive scan RGB CMOS 1/2.9”
    Lens 4.7–84.6 mm, F1.6–2.8 Horizontal field of view 59°–4° V ertical field of view 35°–2° Autofocus
    Day/Night Automatically removable infrared-cut filter
    Minimum Ilumination Color: 0.5 lux at 30 IRE F1.6 B/W: 0.04 lux at 30 IRE F1.6
    Shutter Time 1/28000 s to 2 s
    Pant/Tilt/Zoom 18x optical zoom and 12x digital zoom, total 2 16x zoom 64 preset positions
    Video H.264 (MPEG - 4 P art 1 0/A VC) Baseline, and Main profiles Motion JPEG
    Resolution 1920x1 080 HD TV 1 080p to 160x90
    Frame Rate Up to 30/25 fps (60/50 Hz) in all resolutions
    Video Streaming Multiple, individually configurable streams in H.264 and Motion JPEG Controllable frame rate and bandwidth VBR/CBR H.264
    Image settings Compression, color , brightness, sharpness, white balance, exposure control, exposure zones, backlight compensation, WDR – dynamic contrast, fine tuning of behavior at low light, rotation, text and image overlay , day/night shift level
    Security P assword protection, IP address filtering, HTTPS a encryption, Digest authentication, User access log, Centralized Certificate Management
    Supported Protocols IPv4/v6, HTTP , HTTPS a , SSL/TLS a , QoS Layer 3 DiffServ , FTP , SFTP , CIFS/SMB, SMTP , Bonjour , UPnP T M , SNMP v1/v2c/v3 (MIB - II), DNS, DynDNS, NTP , RTSP , RTP , T CP , UDP , IGMP , RT CP , ICMP , DHCP , ARP , SOCKS, SSH
    Aplication Programming Interface Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www .axis.com AXIS Video Hosting System (A VHS) with One - Click Connection ONVIF® Profile S and ONVIF® Profile G, specification at www .onvif.org
    Analytics AXIS Video Motion Detection 4, active tampering alarm Support for AXIS Camera Application Platform enabling installation of third - party applications, see www .axis.com/acap
    Event Triggers Analytics, Edge storage events
    Event actions File upload: FTP, HTTP, network share and email Notification: email, HTTP and TCP Pre- and post-alarm video buffering
    Data streaming Event data
    Built-in installation aids Pixel counter
    Casing IP66 - and IP67 - rated, electropolished SAE 3 16L stainless steel casing for maximum corrosion protection
    Memory 256 MB RAM, 128 MB Flash
    Power 24 Volt
    Connectors XF40 - Q1765 models: Three M20 conduit entries XF40 - Q1765 UL models: Three 3/4" NPT conduit entires
    Storage Support for microSD/microSDHC/microSDXC card Support for SD card encryption Support for recording to network - attached storage (NAS) For SD card and NAS recommendations see www .axis.com
    Operation condition XF40 - Q1765: - 40 °C to 7 0 °C ( - 40 °F to 158 °F) XF40 - Q1765 - 60 C: - 60 °C to 40 °C ( - 76 °F to 1 04 °F) XF40 - Q1765 - 50 C UL: - 50 °C to 7 0 °C ( - 58 °F to 158 °F) Humidity 1 0–1 00% RH (condensing)
