    AXIS XF40-Q1765-60 EAC

    Telp untuk Harga
    Axis XF40-Q1765 EAC -60C
    Type: IP security camera
    Placement supported: Indoor & outdoor
    Form factor: Bullet, Colour of product: Stainless steel
    Protection features: Corrosion resistant, Explosion proof, Shock resistant
    Maximum resolution: 1920 x 1080 pixels
    Video compression formats: H.264,M-JPEG,MPEG4
    Supported graphics resolutions: 160 x 90,1920 x 1080 (HD 1080)
    Minimum illumination: 0.04 lx, Viewing angle
    horizontal: 59°, Viewing angle, vertical: 35°
    Sensor type: CMOS, Optical sensor size: 25.4 / 2.9 mm (1 / 2.9")

    XF40-Q1765 EAC Explosion-Protected Network Camera

    - Certified for hazardous areas
    - Stainless steel (SAE 316L) and impact resistance
    - Full HDTV 1080p resolution
    - 18x zoom and autofocus
    - Wide temperature range

    Many variants for worldwide coverage

    XF40-Q1765 Explosion-Protected Network Camera comprises different variants, certified for hazardous areas according to different regulations valid in different countries. Depending on the variants, the camera features may differ. For instance the UL certified model, XF40-Q1765 -50 C UL, offers three 3/4" NPT conduit entries, while XF40-Q1765 and XF40-Q1765 -60 C models offer three M20 conduit entries. All versions of XF40-Q1765 have a 24 V AC power input. For more information, check the product specific datasheet.

    Combining technologies

    XF40-Q1765 Explosion-Protected Network Camera is an AXIS Q1765-LE Camera (excl. IR LEDs and SD card, incl. wiper and support for washer) mounted inside an explosion-protected stainless steel housing. The camera provides superb image quality and color fidelity, and offers full HDTV 1080p resolution at 25/30 fps. With 18x optical zoom and autofocus, the camera is ideally suited for remote monitoring situations common in hazardous areas. The camera features an electropolished 316L stainless steel housing certified for hazardous areas according to, among others, ATEX, IECEx and UL.

    Critical infrastructure

    XF40-Q1765 is ideally suited for video surveillance monitoring in hazardous areas in critical infrastructure such as onshore, offshore and marine environments in the oil and gas industry. In addition, typical application areas are also dusty environments in other industries, for example, paper and textile industries, and grain handling.

    Wide temperature range

    The outdoor-ready XF40-Q1765 comes in two product versions, depending on the required operating temperature range: either up to 60 ºC (140 ºF) or down to -60 ºC (-76 ºF). A removable sunshield is supplied with the camera.

    Flexible integration and remote accessibility

    XF40-Q1765 provides a high level of flexible integration possibilities with other equipment, such as access control, illumination and audio. It offers remote accessibility, using any existing IP-based networks. XF40-Q1765 for hazardous areas is a complement to Axis’ wide range of network cameras that can be used in safe areas.

    Spesifikasi produk
    Image Sensor Progressive scan RGB CMOS 1/2.9”
    Lens 4.7–84.6 mm, F1.6–2.8 Horizontal field of view 59°–4° V ertical field of view 35°–2° Autofocus
    Day/Night Automatically removable infrared-cut filter
    Minimum Ilumination Color: 0.5 lux at 30 IRE F1.6 B/W: 0.04 lux at 30 IRE F1.6
    Shutter Time 1/28000 s to 2 s
    Pant/Tilt/Zoom 18x optical zoom and 12x digital zoom, total 2 16x zoom 64 preset positions
    Video H.264 (MPEG - 4 P art 1 0/A VC) Baseline, and Main profiles Motion JPEG
    Resolution 1920x1 080 HD TV 1 080p to 160x90
    Frame Rate Up to 30/25 fps (60/50 Hz) in all resolutions
    Video Streaming Multiple, individually configurable streams in H.264 and Motion JPEG Controllable frame rate and bandwidth VBR/CBR H.264
    Image settings Compression, color , brightness, sharpness, white balance, exposure control, exposure zones, backlight compensation, WDR – dynamic contrast, fine tuning of behavior at low light, rotation, text and image overlay , day/night shift level
    Security P assword protection, IP address filtering, HTTPS a encryption, Digest authentication, User access log, Centralized Certificate Management
    Supported Protocols IPv4/v6, HTTP , HTTPS a , SSL/TLS a , QoS Layer 3 DiffServ , FTP , SFTP , CIFS/SMB, SMTP , Bonjour , UPnP T M , SNMP v1/v2c/v3 (MIB - II), DNS, DynDNS, NTP , RTSP , RTP , T CP , UDP , IGMP , RT CP , ICMP , DHCP , ARP , SOCKS, SSH
    Aplication Programming Interface Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www .axis.com AXIS Video Hosting System (A VHS) with One - Click Connection ONVIF® Profile S and ONVIF® Profile G, specification at www .onvif.org
    Analytics AXIS Video Motion Detection 4, active tampering alarm Support for AXIS Camera Application Platform enabling installation of third - party applications, see www .axis.com/acap
    Event Triggers Analytics, Edge storage events
    Event actions File upload: FTP, HTTP, network share and email Notification: email, HTTP and TCP Pre- and post-alarm video buffering
    Data streaming Event data
    Built-in installation aids Pixel counter
    Casing IP66 - and IP67 - rated, electropolished SAE 3 16L stainless steel casing for maximum corrosion protection
    Memory 256 MB RAM, 128 MB Flash
    Power 24 Volt
    Connectors XF40 - Q1765 models: Three M20 conduit entries XF40 - Q1765 UL models: Three 3/4" NPT conduit entires
    Storage Support for microSD/microSDHC/microSDXC card Support for SD card encryption Support for recording to network - attached storage (NAS) For SD card and NAS recommendations see www .axis.com
    Operation condition XF40 - Q1765: - 40 °C to 7 0 °C ( - 40 °F to 158 °F) XF40 - Q1765 - 60 C: - 60 °C to 40 °C ( - 76 °F to 1 04 °F) XF40 - Q1765 - 50 C UL: - 50 °C to 7 0 °C ( - 58 °F to 158 °F) Humidity 1 0–1 00% RH (condensing)
    *
    *
    *

    XF40-Q1765 EAC Explosion-Protected Network Camera

    - Certified for hazardous areas
    - Stainless steel (SAE 316L) and impact resistance
    - Full HDTV 1080p resolution
    - 18x zoom and autofocus
    - Wide temperature range

    Many variants for worldwide coverage

    XF40-Q1765 Explosion-Protected Network Camera comprises different variants, certified for hazardous areas according to different regulations valid in different countries. Depending on the variants, the camera features may differ. For instance the UL certified model, XF40-Q1765 -50 C UL, offers three 3/4" NPT conduit entries, while XF40-Q1765 and XF40-Q1765 -60 C models offer three M20 conduit entries. All versions of XF40-Q1765 have a 24 V AC power input. For more information, check the product specific datasheet.

    Combining technologies

    XF40-Q1765 Explosion-Protected Network Camera is an AXIS Q1765-LE Camera (excl. IR LEDs and SD card, incl. wiper and support for washer) mounted inside an explosion-protected stainless steel housing. The camera provides superb image quality and color fidelity, and offers full HDTV 1080p resolution at 25/30 fps. With 18x optical zoom and autofocus, the camera is ideally suited for remote monitoring situations common in hazardous areas. The camera features an electropolished 316L stainless steel housing certified for hazardous areas according to, among others, ATEX, IECEx and UL.

    Critical infrastructure

    XF40-Q1765 is ideally suited for video surveillance monitoring in hazardous areas in critical infrastructure such as onshore, offshore and marine environments in the oil and gas industry. In addition, typical application areas are also dusty environments in other industries, for example, paper and textile industries, and grain handling.

    Wide temperature range

    The outdoor-ready XF40-Q1765 comes in two product versions, depending on the required operating temperature range: either up to 60 ºC (140 ºF) or down to -60 ºC (-76 ºF). A removable sunshield is supplied with the camera.

    Flexible integration and remote accessibility

    XF40-Q1765 provides a high level of flexible integration possibilities with other equipment, such as access control, illumination and audio. It offers remote accessibility, using any existing IP-based networks. XF40-Q1765 for hazardous areas is a complement to Axis’ wide range of network cameras that can be used in safe areas.

    Spesifikasi produk
    Image Sensor Progressive scan RGB CMOS 1/2.9”
    Lens 4.7–84.6 mm, F1.6–2.8 Horizontal field of view 59°–4° V ertical field of view 35°–2° Autofocus
    Day/Night Automatically removable infrared-cut filter
    Minimum Ilumination Color: 0.5 lux at 30 IRE F1.6 B/W: 0.04 lux at 30 IRE F1.6
    Shutter Time 1/28000 s to 2 s
    Pant/Tilt/Zoom 18x optical zoom and 12x digital zoom, total 2 16x zoom 64 preset positions
    Video H.264 (MPEG - 4 P art 1 0/A VC) Baseline, and Main profiles Motion JPEG
    Resolution 1920x1 080 HD TV 1 080p to 160x90
    Frame Rate Up to 30/25 fps (60/50 Hz) in all resolutions
    Video Streaming Multiple, individually configurable streams in H.264 and Motion JPEG Controllable frame rate and bandwidth VBR/CBR H.264
    Image settings Compression, color , brightness, sharpness, white balance, exposure control, exposure zones, backlight compensation, WDR – dynamic contrast, fine tuning of behavior at low light, rotation, text and image overlay , day/night shift level
    Security P assword protection, IP address filtering, HTTPS a encryption, Digest authentication, User access log, Centralized Certificate Management
    Supported Protocols IPv4/v6, HTTP , HTTPS a , SSL/TLS a , QoS Layer 3 DiffServ , FTP , SFTP , CIFS/SMB, SMTP , Bonjour , UPnP T M , SNMP v1/v2c/v3 (MIB - II), DNS, DynDNS, NTP , RTSP , RTP , T CP , UDP , IGMP , RT CP , ICMP , DHCP , ARP , SOCKS, SSH
    Aplication Programming Interface Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www .axis.com AXIS Video Hosting System (A VHS) with One - Click Connection ONVIF® Profile S and ONVIF® Profile G, specification at www .onvif.org
    Analytics AXIS Video Motion Detection 4, active tampering alarm Support for AXIS Camera Application Platform enabling installation of third - party applications, see www .axis.com/acap
    Event Triggers Analytics, Edge storage events
    Event actions File upload: FTP, HTTP, network share and email Notification: email, HTTP and TCP Pre- and post-alarm video buffering
    Data streaming Event data
    Built-in installation aids Pixel counter
    Casing IP66 - and IP67 - rated, electropolished SAE 3 16L stainless steel casing for maximum corrosion protection
    Memory 256 MB RAM, 128 MB Flash
    Power 24 Volt
    Connectors XF40 - Q1765 models: Three M20 conduit entries XF40 - Q1765 UL models: Three 3/4" NPT conduit entires
    Storage Support for microSD/microSDHC/microSDXC card Support for SD card encryption Support for recording to network - attached storage (NAS) For SD card and NAS recommendations see www .axis.com
    Operation condition XF40 - Q1765: - 40 °C to 7 0 °C ( - 40 °F to 158 °F) XF40 - Q1765 - 60 C: - 60 °C to 40 °C ( - 76 °F to 1 04 °F) XF40 - Q1765 - 50 C UL: - 50 °C to 7 0 °C ( - 58 °F to 158 °F) Humidity 1 0–1 00% RH (condensing)
