    AXIS XF40-Q1765-60 CSA

    Telp untuk Harga
    * Certified for hazardous areas by Oxalis Group Ltd. by Eatonr
    * Electro-polished 316L stainless steel housingr
    * Full HDTV 1080p resolutionr
    * 18x zoom and autofocusr
    * Two product versions, depending on temperature range neededr
    * Wide Dynamic Ranger
    * Explosion-protected 316L stainless steel fixed network camera certified for hazardous areas according to cLCus.r
    * Certification part code 1410-15-00.r
    * Oxalis housing with 3/4" NPT,r
    * Axis 1080p HDTV camera with 18x optical zoom,r
    * Auto focus and day/night mode. Multiple,r
    * Individually configurable H.264 and Motion JPEG streams;r
    * Max HDTV 1080p resolution at 25/30 fps.r
    * WDR- dynamic contrast. Video motion detection and active tampering alarm.r
    * IP66 and IP67-rated and operating temperature in -60°C to +40°C ( -76ºF to +104ºF).r
    * Powered by 24 V AC (Power supply not included).r
    * Includes a removable sunshield.r

    AXIS XF40-Q1765-60C CSA

    Explosion-protected 316L stainless steel fixed network camera certified for hazardous areas according to CSA. Certification part code 1410-15-00. Oxalis housing, Axis 1080p HDTV camera with 18x optical zoom, auto focus and day/night mode. Multiple, individually configurable H.264 and Motion JPEG streams; max HDTV 1080p resolution at 25/30 fps. WDR- dynamic contrast. Video motion detection and active tampering alarm. IP66 and IP67-rated and operating temperature in -60°C to +40°C ( -76ºF to +104ºF). Powered by 24 V AC (Power supply not included). Includes a removable sunshield.

    Spesifikasi produk
    Image Sensor Progressive scan RGB CMOS 1/2.9”
    Lens 4.7–84.6 mm, F1.6–2.8 Horizontal field of view 59°–4° V ertical field of view 35°–2° Autofocus
    Day/Night Automatically removable infrared-cut filter
    Minimum Ilumination Color: 0.5 lux at 30 IRE F1.6 B/W: 0.04 lux at 30 IRE F1.6
    Shutter Time 1/28000 s to 2 s
    Pant/Tilt/Zoom 18x optical zoom and 12x digital zoom, total 2 16x zoom 64 preset positions
    Video H.264 (MPEG - 4 P art 1 0/A VC) Baseline, and Main profiles Motion JPEG
    Resolution 1920x1 080 HD TV 1 080p to 160x90
    Frame Rate Up to 30/25 fps (60/50 Hz) in all resolutions
    Video Streaming Multiple, individually configurable streams in H.264 and Motion JPEG Controllable frame rate and bandwidth VBR/CBR H.264
    Image settings Compression, color , brightness, sharpness, white balance, exposure control, exposure zones, backlight compensation, WDR – dynamic contrast, fine tuning of behavior at low light, rotation, text and image overlay , day/night shift level
    Security P assword protection, IP address filtering, HTTPS a encryption, Digest authentication, User access log, Centralized Certificate Management
    Supported Protocols IPv4/v6, HTTP , HTTPS a , SSL/TLS a , QoS Layer 3 DiffServ , FTP , SFTP , CIFS/SMB, SMTP , Bonjour , UPnP T M , SNMP v1/v2c/v3 (MIB - II), DNS, DynDNS, NTP , RTSP , RTP , T CP , UDP , IGMP , RT CP , ICMP , DHCP , ARP , SOCKS, SSH
    Aplication Programming Interface Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www .axis.com AXIS Video Hosting System (A VHS) with One - Click Connection ONVIF® Profile S and ONVIF® Profile G, specification at www .onvif.org
    Analytics AXIS Video Motion Detection 4, active tampering alarm Support for AXIS Camera Application Platform enabling installation of third - party applications, see www .axis.com/acap
    Event Triggers Analytics, Edge storage events
    Event actions File upload: FTP, HTTP, network share and email Notification: email, HTTP and TCP Pre- and post-alarm video buffering
    Data streaming Event data
    Built-in installation aids Pixel counter
    Casing IP66 - and IP67 - rated, electropolished SAE 3 16L stainless steel casing for maximum corrosion protection
    Memory 256 MB RAM, 128 MB Flash
    Power 24 Volt
    Connectors XF40 - Q1765 models: Three M20 conduit entries XF40 - Q1765 UL models: Three 3/4" NPT conduit entires
    Storage Support for microSD/microSDHC/microSDXC card Support for SD card encryption Support for recording to network - attached storage (NAS) For SD card and NAS recommendations see www .axis.com
    Operation condition XF40 - Q1765: - 40 °C to 7 0 °C ( - 40 °F to 158 °F) XF40 - Q1765 - 60 C: - 60 °C to 40 °C ( - 76 °F to 1 04 °F) XF40 - Q1765 - 50 C UL: - 50 °C to 7 0 °C ( - 58 °F to 158 °F) Humidity 1 0–1 00% RH (condensing)
    *
    *
    *

    AXIS XF40-Q1765-60C CSA

    Explosion-protected 316L stainless steel fixed network camera certified for hazardous areas according to CSA. Certification part code 1410-15-00. Oxalis housing, Axis 1080p HDTV camera with 18x optical zoom, auto focus and day/night mode. Multiple, individually configurable H.264 and Motion JPEG streams; max HDTV 1080p resolution at 25/30 fps. WDR- dynamic contrast. Video motion detection and active tampering alarm. IP66 and IP67-rated and operating temperature in -60°C to +40°C ( -76ºF to +104ºF). Powered by 24 V AC (Power supply not included). Includes a removable sunshield.

    Spesifikasi produk
    Image Sensor Progressive scan RGB CMOS 1/2.9”
    Lens 4.7–84.6 mm, F1.6–2.8 Horizontal field of view 59°–4° V ertical field of view 35°–2° Autofocus
    Day/Night Automatically removable infrared-cut filter
    Minimum Ilumination Color: 0.5 lux at 30 IRE F1.6 B/W: 0.04 lux at 30 IRE F1.6
    Shutter Time 1/28000 s to 2 s
    Pant/Tilt/Zoom 18x optical zoom and 12x digital zoom, total 2 16x zoom 64 preset positions
    Video H.264 (MPEG - 4 P art 1 0/A VC) Baseline, and Main profiles Motion JPEG
    Resolution 1920x1 080 HD TV 1 080p to 160x90
    Frame Rate Up to 30/25 fps (60/50 Hz) in all resolutions
    Video Streaming Multiple, individually configurable streams in H.264 and Motion JPEG Controllable frame rate and bandwidth VBR/CBR H.264
    Image settings Compression, color , brightness, sharpness, white balance, exposure control, exposure zones, backlight compensation, WDR – dynamic contrast, fine tuning of behavior at low light, rotation, text and image overlay , day/night shift level
    Security P assword protection, IP address filtering, HTTPS a encryption, Digest authentication, User access log, Centralized Certificate Management
    Supported Protocols IPv4/v6, HTTP , HTTPS a , SSL/TLS a , QoS Layer 3 DiffServ , FTP , SFTP , CIFS/SMB, SMTP , Bonjour , UPnP T M , SNMP v1/v2c/v3 (MIB - II), DNS, DynDNS, NTP , RTSP , RTP , T CP , UDP , IGMP , RT CP , ICMP , DHCP , ARP , SOCKS, SSH
    Aplication Programming Interface Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www .axis.com AXIS Video Hosting System (A VHS) with One - Click Connection ONVIF® Profile S and ONVIF® Profile G, specification at www .onvif.org
    Analytics AXIS Video Motion Detection 4, active tampering alarm Support for AXIS Camera Application Platform enabling installation of third - party applications, see www .axis.com/acap
    Event Triggers Analytics, Edge storage events
    Event actions File upload: FTP, HTTP, network share and email Notification: email, HTTP and TCP Pre- and post-alarm video buffering
    Data streaming Event data
    Built-in installation aids Pixel counter
    Casing IP66 - and IP67 - rated, electropolished SAE 3 16L stainless steel casing for maximum corrosion protection
    Memory 256 MB RAM, 128 MB Flash
    Power 24 Volt
    Connectors XF40 - Q1765 models: Three M20 conduit entries XF40 - Q1765 UL models: Three 3/4" NPT conduit entires
    Storage Support for microSD/microSDHC/microSDXC card Support for SD card encryption Support for recording to network - attached storage (NAS) For SD card and NAS recommendations see www .axis.com
    Operation condition XF40 - Q1765: - 40 °C to 7 0 °C ( - 40 °F to 158 °F) XF40 - Q1765 - 60 C: - 60 °C to 40 °C ( - 76 °F to 1 04 °F) XF40 - Q1765 - 50 C UL: - 50 °C to 7 0 °C ( - 58 °F to 158 °F) Humidity 1 0–1 00% RH (condensing)
