Image Sensor
|
1/2.8” Exmor CMOS |
Effective Pixels
|
1944(H) x 1092(V), 2 Megapixels |
Scanning System
|
Progressive |
Electronic Shutter Speed
|
1/1 ~ 1/30,000s |
Min.Illumination
|
Color: 0.05Lux@F1.6,B/W: 0.005Lux@F1.6 |
S/N RATIO
|
More than 50dB |
Video Output
|
BNC(1.0Vp-p/75Ω), PAL / NTSC |
Day/Night
|
Auto(ICR) / Color / B/W |
Backlight Compensation
|
BLC / HLC / DWDR (Digital WDR) |
White Balance
|
Auto, ATW, Indoor, Outdoor, Manual |
Gain Control
|
Auto / Manual |
Noise Reduction
|
Ultra DNR (2D/3D) |
Privasi masking
|
Up to 24 areas |
Digital Zoom
|
16x |
Defog
|
On / Off |
Focal length
|
4.3mm~129mm (30x Optical zoom) |
Max. Aperture Ratio
|
F1.6 ~ F4.7 |
Focus Control
|
Auto / Manual |
Angle of View
|
H: 65.1°~ 2.34° |
Close Focus Distance
|
100mm ~ 1000mm |
PAN/TILT
|
Pan: 0° ~ 360° endless; Tilt: -2° ~ 90°, auto flip 180° |
Manual Control Speed
|
n Pan: 0.1° ~ 300°/s; Tilt: 0.1° ~250°/s |
Preset Speed
|
Pan: 400°/s; Tilt: 300°/s |
Preset Points
|
80(DH-SD), 255(Pelco-P/D) |
PTZ Mode
|
5 Pattern, 8 Tour, Auto Pan, Auto Scan |
Speed Setup
|
Human-oriented focal length/ speed adaptation |
Power Up Action
|
Auto restore to previous PTZ and lens status after power failure |
Idle Motion
|
Activate Preset/Pan/Scan/Tour/Pattern if there is no command in the specified period |
Time task
|
Auto activation of Preset/Pan/Scan/Tour/Pattern by preset-time |
Protocol
|
DH-SD (Auto recognition) |
Compression
|
H.264 / MJPEG |
Resolution
|
1080P(1920×1080)/ 720P(1280×720) / D1(704×576/704×480) / CIF(352×288/352×240) |
Frame Rate
|
1080P (1 ~ 25/30fps) / 720P(1~50/60fps); D1/CIF(1 ~ 25/30fps); 720P/D1/CIF(1 ~ 25/30fps) |
Bit rate
|
H.264: 56K ~ 8192Kbps, MJPEG: 56K ~ 20480Kbps |
Audio Compression
|
G.711a / G.711u (32kbps) / PCM (128kbps) |
Interface
|
1/1 channel In/Out |
Auto Tracking
|
Single-scene, multiple-scene, panorama-scene |
IVS Support
|
Tripwire, Cross Warning Zone, Perimeter Protection, Loitering Detection, Abandoned Object Detection, Missing Object Detection, Illegal Parking, Fast Moving and etc |
Trigger Mode
|
Manual / Auto (alarm triggered) |
Trigger Events
|
Targeting, Zoom, Tracking, Recording, Snapshot, Alarm and etc |
Ethernet
|
RJ-45 (10/100Base-T) |
Network Protocol
|
IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour |
Compatibility
|
ONVIF PSIA CGI |
Max. User Access
|
20 users |
Smart Phone (Platform)
|
iPhone, iPad, Android, Windows Phone |
Memory Slot
|
Micro SD, Max 64GB |
Alarm Events
|
7/2 channel In/Out |
Power Supply
|
AC 24V/3A (±10%) |
Power Consumption (±10%)
|
20W, 45W(Heater on) |
Working Temperature/Humidity
|
-40ºC ~ 60ºC / Less than 90% RH |
Ingress Protection
|
IP67 |
Vandal Resistance
|
IK10(Optional) |
Dimensions (mm)
|
Φ222(mm) x 322(mm) |
Weight
|
5.0kg |
