Image Sensor
|
1/2.8” CMOS |
Effective Pixels
|
1944(H) x 1092(V), 2Megapixels |
Scanning System
|
Progressive |
Electronic Shutter Speed
|
1/3 ~ 1/30,000s |
Min.Illumination
|
Color: 0.05Lux@F1.6; B/W: 0.005Lux@F1.6, 0Lux (IR on) |
S/N RATIO
|
More than 55dB |
Day/Night
|
Auto(ICR) / Color / B/W |
Backlight Compensation
|
BLC / HLC / DWDR (Digital WDR) |
White Balance
|
Auto, ATW, Indoor, Outdoor, Manual |
Gain Control
|
Auto / Manual |
Noise Reduction
|
Ultra DNR (2D/3D) |
Privasi masking
|
Up to 24 areas |
Digital Zoom
|
16x |
Focal length
|
4.3mm~129mm (30x Optical zoom) |
Max. Aperture Ratio
|
F1.6~ F5.0 |
Focus Control
|
Auto / Manual |
Angle of View
|
H: 65.1° ~ 2.34° |
Close Focus Distance
|
100mm~ 1000mm |
PAN/TILT
|
Pan: 0° ~ 360° endless; Tilt: -15° ~ 90°, auto flip 180° |
Manual Control Speed
|
Pan: 0.1° ~300° /s; Tilt: 0.1° ~200° /s |
Preset Speed
|
Pan: 400° /s; Tilt: 300° /s |
Preset Points
|
300 |
PTZ Mode
|
5 Pattern, 8 Tour, Auto Pan, Auto Scan |
Speed Setup
|
Human-oriented focal length/ speed adaptation |
Power Up Action
|
Auto restore to previous PTZ and lens status after power failure |
Idle Motion
|
Activate Preset/ Pan/ Scan/ Tour/ Pattern if there is no command in the specified period |
IR distance
|
80m (DC12V) / 100m (AC24V) |
Compression
|
H.264 / MJPEG |
Resolution
|
1080P(1920×1080)/ 720P(1280×720) / D1(704×576/ 704×480) /CIF (352×288/352×240) |
Frame Rate
|
1080P/ D1 (1 ~ 25/30fps), 720P(1~50/60fps) & D1/CIF(1 ~ 25/30fps) |
Bit rate
|
H.264: 448K ~ 8192Kbps, MJPEG: 5120K ~ 10240Kbps |
Audio Compression
|
G.711a / G.711Mu(32kbps)/ PCM(128kbps) |
Interface
|
1/1 channel In/Out |
Ethernet
|
RJ-45 (10/100Base-T) |
Network Protocol
|
IPv4/ IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x |
Compatibility
|
ONVIF PSIA CGI |
Max. User Access
|
20 users |
Smart Phone (Platform)
|
iPhone, iPad, Android, Windows Phone |
Memory Slot
|
Micro SD, Max 64GB |
Alarm Events
|
2/1 channel In/Out |
Power Supply
|
AC24V/ DC12V, POE plus(802.3at) |
Power Consumption (±10%)
|
DC12V: 13W, 20W (IR on) AC24V: 13W, 23W (IR on) |
Working Temperature/Humidity
|
DC12V: -30ºC ~ 60ºC / Less than 90% RH AC24V: -40ºC ~ 70ºC / Less than 90% RH |
Ingress Protection
|
IP66 |
Dimensions (mm)
|
Φ186.0(mm) x 309(mm) |
Weight
|
3.5kg |
