Image Sensor
|
Uncooled Micro bolometer 384x288, pixel pitch: 17µm |
Lens
|
mm: 55° viewa , F1.2 13 mm: 28° viewa , F1.0 35 mm: 10.7° viewa , F1.2 60 mm: 6.2° viewa , F1.25 |
Sensitivity
|
NETD < 70 mK |
Video Compression
|
H.264 (MPEG-4 Part 10/AVC), H.264 Main and Baseline Profile Motion JPEG |
Video Resolution
|
Sensor is 384x288. Image can be scaled up to 768x576 |
Video Framerate
|
Up to 30 fps within EU, Norway, Switzerland, Canada, USA, Japan, Australia, New Zealand Up to 8.3 fps in other countriesb |
Video Streaming
|
At least three H.264 and Motion JPEG streams using the same palette, simultaneous and individually configured in max. resolution at 30 fps Controllable frame rate and bandwidth VBR/CBR H.264 |
Image settings
|
Axis' Corridor Format |
Audio streaming
|
Two-way, full duplex |
Audio Compression
|
AAC LC 8/16 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz Configurable bit rate |
Audio Input / Output
|
External microphone or line input, line output |
Security
|
Password protection, IP address filtering, HTTPSc encryption, IEEE 802.1Xc network access control, Digest authentication, User access log |
Protocol Support
|
IPv4/v6, HTTP, HTTPSc , SSL/TLSc , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH |
Application Programming Interface
|
Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www.axis.com AXIS Video Hosting System (AVHS) with One-Click Camera Connection ONVIF Profile S; specification at www.onvif.org |
Intelligent Video
|
Audio detection |
Trigger Events
|
Intelligent video, Temperature, External input, Time scheduled, Shock detection, Edge storage events, Audio |
Event actions
|
File upload: FTP, HTTP, network share and email Notification: email, HTTP and TCP, External output activation Pre- and post-alarm video buffering Video recording to edge storage, Audio recording to edge storage |
Data streaming
|
Event data |
Casing
|
IP66-rated metal casing (Aluminium) with integrated dehumidifying membrane and a germanium window Color: White NCS S 1002-B |
Memory
|
256 MB RAM, 128 MB Flash |
Power
|
Power over Ethernet IEEE 802.3af/802.3at Type 1 Class 3, max. 10 W 8-28 V DC, max. 11 W or 20-24 V AC 50-60 Hz, max. 15 VA, power supply not included |
Connectors
|
RJ45 10BASE-T/100BASE-TX PoE, terminal block for power, Eight circuit PCB header for two configurable inputs/outputs and audio |
Edge Storage
|
microSD/microSDHC/microSDXC slot supporting memory card up to 64 GB (card not included) Support for recording to dedicated network-attached storage (NAS) |
Operating Conditions
|
-40 °C to 60 °C (-40 °F to 140 °F) Humidity 10-100% RH (condensing) |
Approvals
|
EN 55022 Class B, FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR22 Class B, KCC KN22 Class B, KN24 |
Weight
|
2200 g (4.9 lb) |
Included accessories
|
Wall and ceiling mount bracket, Pipe converter for US, RJ45 network cable 5 m (16 ft) |
Video Management Software
|
AXIS Camera Companion (included), AXIS Camera Station and video management software from Axis’ Application Development Partners (not included). For more information, see www.axis.com/products/video/software |
