Brand: Axis

Axis Q1604

Telp untuk Harga

Wide Dynamic Range with dynamic capture at HDTV 720p
Remote back focus capability
Day/night functionality
Multiple H.264 video streams
Power over Ethernet

Qty:

Overview
Specifications
Contact Us

AXIS Q1604 NETWORK CAMERA

Network Camera AXIS Q1604 harga ekonomis dan bersahabat di Jakarta. Network kamera adalah kamera pengawas yang sudah dapat terhubung melalui jaringan, sehingga pengguna dapat memantau aktifitas dari jarak jauh. Kamera AXIS Q1604 dengan System Day/Night sehingga akan tetap memberikan performa yang baik pada siang dan malam hari. Fitur edge storage SD/SDHC/SDXC yang telah mendukung slot kartu microSD merupakan fitur yang menyediakan slot untuk penyimpanan kartu microSD langsung pada kamera dengan maksimal kapasitas hingga 64 GB. Dengan memori 256 MB RAM, 128 MB Flash kamera AXIS Q1604 mampu beroperasi dengan sangat optimal.

Kamera dengan kualitas teknologi yang canggih telah mampu mendukung beberapa protocol seperti IPv4/v6, HTTP, HTTPSc , SSL/TLSc , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS. AXIS CCTV sangat tepat untuk pengawasan di era saat ini karena telah dilengkapi dengan berbagai teknologi terbaru. Adapun beragam keunggulan lainnya yang ditawarkan oleh Q1604 yaitu mampu bertahan pada suhu 0 °C to 50 °C (32 °F to 122 °F) disertai pula dengan katahanan casing yang memiliki rating IP66 sehingga mampu bertahan terhadap lingkungan keras di sekitar kamera.

FITUR AXIS Q1604

Video kamera CCTV dengan kualitas luar biasa.
Multiple-stream H 264.
RJ45 10BASE-T/100BASE-TX PoE, 3.5 mm mic/line in, 3.5 mm line DC input.
Memori: 256 MB RAM, 128 MB Flash.
Berat CCTV 600 g (1.3 lb).
Casing Metal (zinc).
Edge Storage, untuk kartu microSD sebagai sarana penyimpanan hasil rekaman.
Kamera yang mudah dipasang dengan berbagai posisi.

Kami menyediakan paket CCTV murah dan paket DVR murah mulai dari jual IP camera, jual IR camera, jual Analog camera, jual Dome camera, jual Cube camera, jual Box camera serta jual DVR 4 channels, jual DVR 6 channels, jual DVR 8 channels, jual DVR 12 channels, jual DVR 16 channels, jual DVR 32 channels.Kamera network AXIS Q1604 hanya bisa Anda dapatkan hanya di JakartaCCTV dengan harga network cctv murah. Jual 16CH DVRmurah di Jakarta hanya di JakartaCCTV. JakartaCCTV terpercaya dan berpengalaman. Pemasangan CCTV yang langsung ditangani oleh teknisi yang berpengalaman.

Spesifikasi produk

Image Sensor	Progressive scan RGB CMOS 1/3”
Lens	2.8–8 mm: 100°–34° viewa , F1.2
Day/Night	Automatically removable infrared-cut filter
Min.Illumination	Color: 0.1 lux, B/W: 0.02 lux, F1.2 With WDR-Dynamic Capture: Color: 0.4 lux, B/W: 0.06 lux, F1.2
Shutter Time	1/29500 to 2 s
Video Compression	H.264 (MPEG-4 Part 10/AVC), H.264 Main and Baseline Profile, Motion JPEG
Video Resolution	1280x960b (1 MP) to 160x90
Video Framerate	25/30 fps
Video Streaming	Multiple, individually configurable streams in H.264/Motion JPEG, Controllable frame rate and bandwidth, VBR H.264
Image settings	WDR-Dynamic Capture: Up to 120 dB depending on scene, Day/Night shift level, Shadow and highlight recovery
Audio streaming	Two-way
Audio Compression	AAC-LC 8/16 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz, Configurable bit rate
Audio Input / Output	Built-in microphone (can be disabled)
Security	Password protection, IP address filtering, HTTPSc encryption, IEEE 802.1Xc network access control, Digest authentication, User access log
Protocol Support	IPv4/v6, HTTP, HTTPSc , SSL/TLSc , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Application Programming Interface	Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www.axis.com. AXIS Video Hosting System (AVHS) with One-Click Camera Connection ONVIF Profile S; specification available at www.onvif.org
Intelligent Video	Video motion detection, Active tampering alarm, Audio detection, Support for AXIS Camera Application Platform enabling installation of AXIS Video Motion Detection 3, AXIS Cross Line Detection, AXIS Digital Autotracking and third-party applications, see www.axis.com/acap
Trigger Events	Intelligent video, Edge storage events, External input
Event actions	File upload: FTP, HTTP, HTTPS, network share and email Send video clip Notification: email, HTTP, HTTPS and TCP Overlay text, Send SNMP Trap Video and audio recording to edge storage Pre- and post-alarm video buffering External output activation, Day/night vision mode, Play audio clip, Status LED, WDR mode
Data streaming	Event data
Built-in installation aids	Focus assistant, Pixel counter, Remote back focus
Casing	Camera: Metal (zinc)
Memory	256 MB RAM, 128 MB Flash
Power	8–20 V DC or Power over Ethernet IEEE 802.3af/802.3at Type 1 Class 3, max. 6.9 W
Connectors	DC input
Edge Storage	SD/SDHC/SDXC slot supporting memory card up to 64 GB (card not included)
Operating Conditions	0 °C to 50 °C (32 °F to 122 °F)
Approvals	KCC KN22 Class B, KN24
Weight	600 g (1.3 lb)
Included accessories	Stand, Connector kit, Resistorx T20 tool, Installation Guide, Installation and Management Software CD, Windows decoder 1-user license
Video Management Software	AXIS Camera Station and video management software from Axis’ Application Development Partners (not included). For more information, see: www.axis.com/products/video/software

Namamu *

Email Anda *

Pertanyaan *

AXIS Q1604 NETWORK CAMERA

FITUR AXIS Q1604

Video kamera CCTV dengan kualitas luar biasa.
Multiple-stream H 264.
RJ45 10BASE-T/100BASE-TX PoE, 3.5 mm mic/line in, 3.5 mm line DC input.
Memori: 256 MB RAM, 128 MB Flash.
Berat CCTV 600 g (1.3 lb).
Casing Metal (zinc).
Edge Storage, untuk kartu microSD sebagai sarana penyimpanan hasil rekaman.
Kamera yang mudah dipasang dengan berbagai posisi.

Spesifikasi produk

Image Sensor	Progressive scan RGB CMOS 1/3”
Lens	2.8–8 mm: 100°–34° viewa , F1.2
Day/Night	Automatically removable infrared-cut filter
Min.Illumination	Color: 0.1 lux, B/W: 0.02 lux, F1.2 With WDR-Dynamic Capture: Color: 0.4 lux, B/W: 0.06 lux, F1.2
Shutter Time	1/29500 to 2 s
Video Compression	H.264 (MPEG-4 Part 10/AVC), H.264 Main and Baseline Profile, Motion JPEG
Video Resolution	1280x960b (1 MP) to 160x90
Video Framerate	25/30 fps
Video Streaming	Multiple, individually configurable streams in H.264/Motion JPEG, Controllable frame rate and bandwidth, VBR H.264
Image settings	WDR-Dynamic Capture: Up to 120 dB depending on scene, Day/Night shift level, Shadow and highlight recovery
Audio streaming	Two-way
Audio Compression	AAC-LC 8/16 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz, Configurable bit rate
Audio Input / Output	Built-in microphone (can be disabled)
Security	Password protection, IP address filtering, HTTPSc encryption, IEEE 802.1Xc network access control, Digest authentication, User access log
Protocol Support	IPv4/v6, HTTP, HTTPSc , SSL/TLSc , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Application Programming Interface	Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www.axis.com. AXIS Video Hosting System (AVHS) with One-Click Camera Connection ONVIF Profile S; specification available at www.onvif.org
Intelligent Video	Video motion detection, Active tampering alarm, Audio detection, Support for AXIS Camera Application Platform enabling installation of AXIS Video Motion Detection 3, AXIS Cross Line Detection, AXIS Digital Autotracking and third-party applications, see www.axis.com/acap
Trigger Events	Intelligent video, Edge storage events, External input
Event actions	File upload: FTP, HTTP, HTTPS, network share and email Send video clip Notification: email, HTTP, HTTPS and TCP Overlay text, Send SNMP Trap Video and audio recording to edge storage Pre- and post-alarm video buffering External output activation, Day/night vision mode, Play audio clip, Status LED, WDR mode
Data streaming	Event data
Built-in installation aids	Focus assistant, Pixel counter, Remote back focus
Casing	Camera: Metal (zinc)
Memory	256 MB RAM, 128 MB Flash
Power	8–20 V DC or Power over Ethernet IEEE 802.3af/802.3at Type 1 Class 3, max. 6.9 W
Connectors	DC input
Edge Storage	SD/SDHC/SDXC slot supporting memory card up to 64 GB (card not included)
Operating Conditions	0 °C to 50 °C (32 °F to 122 °F)
Approvals	KCC KN22 Class B, KN24
Weight	600 g (1.3 lb)
Included accessories	Stand, Connector kit, Resistorx T20 tool, Installation Guide, Installation and Management Software CD, Windows decoder 1-user license
Video Management Software	AXIS Camera Station and video management software from Axis’ Application Development Partners (not included). For more information, see: www.axis.com/products/video/software
