Image Sensor
|
1/4” progressive scan RGB CMOS |
Lens
|
Fixed iris, fixed focus, 2.8 mm: 81° viewa , F2.0 |
Light sensitivity
|
1.0–10000 lux |
Shutter Time
|
1/24500 s to 1/6 s |
Video Compression
|
H.264 (MPEG-4 Part 10/AVC) Motion JPEG |
Video Resolution
|
1280x720 to 320x180 |
Video Framerate
|
H.264: Up to 25/30 fps (50/60 Hz) in all resolutions Motion JPEG: Up to 25/30 fps (50/60 Hz) in all resolutions |
Video Streaming
|
Multiple, individually configurable streams in H.264 and Motion JPEG Controllable frame rate and bandwidth VBR/CBR H.264 |
Image settings
|
Compression, Color, Brightness, Sharpness, Contrast, White balance, Exposure control, Exposure zones, Backlight compensation, Fine tuning of behavior at low light, Rotation, Text and image overlay, Mirroring of images, Privacy mask, Axis’ Corridor Format |
Security
|
Password protection, IP address filtering, HTTPSb encryption, IEEE 802.1Xb network access control, Digest authentication, User access log |
Protocol Support
|
IPv4/v6, HTTP, HTTPSb , SSL/TLSb , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS |
Application Programming Interface
|
Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www.axis.com AXIS Video Hosting System (AVHS) with One-Click Camera Connection. ONVIF Profile S; specification at www.onvif.org |
Intelligent Video
|
Video motion detection, Active tampering alarm, AXIS Camera Application Platform enabling installation of additional applications |
Trigger Events
|
Intelligent video, External inputs, Video loss |
Event actions
|
File upload: FTP, HTTP, network share and email Notification: email, HTTP and TCP External output activation Video recording to edge storage Pre- and post-alarm video buffering |
Event actions
|
Pixel counter |
Data streaming
|
Event data |
Casing
|
Main unit: polycarbonate casing, sensor unit: IP66- and NEMA 4X-rated metal casing (aluminum) |
Memory
|
256 MB RAM, 128 MB Flash |
Power
|
Power over Ethernet IEEE 802.3af/802.3at Type 1 Class 2 (max 6.49 W) 8–28 V DC max 4.7 W |
Connectors
|
RJ45 for 10BASE-T/100BASE-TX PoE RJ12 for the sensor unit Terminal blocks for power, 1 alarm input and 1 output |
Edge Storage
|
MicroSD/microSDHC/microSDXC slot supporting memory card up to 64 GB (card not included) Support for recording to dedicated network-attached storage (NAS) |
Operating Conditions
|
-20 °C to 50 °C (-4 °F to 122 °F) Main unit: Humidity 10–85% RH (non-condensing), sensor unit: Humidity 10–100% RH (condensing) |
Approvals
|
IEC/EN/UL 60950-22, IEC/EN 60529 IP66, NEMA 250 Type 4X, IEC 60068-2-14, IEC 60068-2-30, IEC 60068-2-78 Class 4K3 |
Weight
|
Main unit: 109 g (0.24 lb), sensor unit: 250 g (0.55 lb) |
Included accessories
|
Mounting kit, Installation Guide, Installation and Management Software CD, Windows decoder 1-user license, AVHS Authentication key |
Video Management Software
|
AXIS Camera Companion (included), AXIS Camera Station and video management software from Axis’ Application Development Partners (not included). For more information, see www.axis.com/products/video/software |
