Image Sensor
|
1/4” progressive scan RGB CMOS |
Lens
|
3.6 mm, F1.8 60° horizontal angle of view |
Min.Illumination
|
1.4 lux, F1.8 |
Shutter Time
|
1/25000 s to 1/6 s |
Pan/ Tilt/ Zoom
|
25 preset positions; Pan: ±180°, 100°/s; Tilt: 90°, 100°/s Zoom: 3x digital zoom |
Video Compression
|
H.264 (MPEG-4 Part 10/AVC) Motion JPEG |
Video Resolution
|
HDTV 720p 1280x720 to 320x180 |
Video Framerate
|
H.264: 30 fps in all resolutions Motion JPEG: 30 fps in all resolutions |
Video Streaming
|
Multiple, individually configurable streams in H.264 and Motion JPEG Controllable frame rate and bandwidth, VBR/CBR H.264 |
Image settings
|
Manual shutter time, Compression, Color, Brightness, Sharpness, Contrast, White balance, Exposure control, Exposure zones, Rotation, Backlight compensation, Fine tuning of behavior at low light, Text overlay |
Audio streaming
|
One-way |
Audio Compression
|
AAC-LC 8/16 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz Configurable bit rate |
Audio Input
|
Built-in microphone |
Security
|
Password protection, IP address filtering, HTTPSa encryption, IEEE 802.1Xa network access control, Digest authentication, User access log |
Protocol Support
|
IPv4/v6, HTTP, HTTPSa , SSL/TLSa , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS |
Application Programming Interface
|
Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www.axis.com ONVIF Profile S, specification at www.onvif.org AXIS Video Hosting System (AVHS) with One-Click Camera Connection. |
Intelligent Video
|
Video motion detection, Audio detection, AXIS Camera Application Platform enabling installation of additional applications |
Trigger Events
|
Video motion detection, Audio detection, AXIS Camera Application Platform, PTZ preset, Memory card full |
Event actions
|
File upload: FTP, HTTP, network share and email Notification: email, HTTP and TCP Go to PTZ preset; Video recording to edge storage Pre- and post-alarm video buffering |
Built-in installation aids
|
Pixel counter |
Casing
|
IP51-rated plastic casing, clear dome |
Memory
|
256 MB RAM, 128 MB Flash |
Power
|
Power over Ethernet 802.3af/802.3at Type 1 Class 3 |
Connectors
|
RJ45 10BASE-T/100BASE-TX PoE |
Edge Storage
|
MicroSD/microSDHC/microSDXC slot supporting memory card up to 64 GB (card not included) Support for recording to network share (network-attached storage or file server) |
Operating Conditions
|
0 °C to 45 °C (32 °F to 113 °F) Humidity 10–85% RH (non-condensing) |
Approvals
|
EN 55022 Class A, EN 61000-6-1, EN 61000-6-2, EN 55024, FCC Part 15 Subpart B Class B, ICES-003 Class A, VCCI Class B, C-tick AS/NZS CISPR 22, KCC KN22 Class A, KN24, EN 60950-1, IEC/EN 60529 IP51 |
Weight
|
330 g (0.7 lb) |
Included accessories
|
Drill template, Mounting brackets for soft and hard ceilings, Installation Guide, Installation and Management Software CD, Windows decoder 1-user license |
Video Management Software
|
AXIS Camera Companion (included), AXIS Camera Station and video management software from Axis’ Application Development Partners (not included). For more information, see www.axis.com/products/video/software |
